WTM5200WB — 925042230 00
WESTINGHOUSE — Fridge
Parts for WTM5200WB
W0018090 BIN FULL WIDTH
W0018093 BIN DOOR FZR
W0018096 BIN HALF WIDTH
.JPG)
W0018109 COVER HINGE RH
W0018128 BIN DELI DEEP
W0018265 BIN CRISPER REAR
$89.05
.JPG)
W0018273 BIN ICE
W0018276 FACIA ASSY CRISPER
W0018291 SUPPORT CENTRE
$15.85
.JPG)
W0018582 BADGE NAMEPLATE
W0019131 SCREW COUNTER SUNK THIMBLE
$4.50
W0034671 TRAY ICE CUBE
.JPG)
W0083263 STOP DOOR
.JPG)
W0085600 CAP LEG
$12.90
W0085609 LEG STABILISING
W0086077 RUNNER RH
W0086637 HOSE DRAIN (SLIT 130MM)
$11.90
.JPG)
W0086638 BLADE FAN
.JPG)
W0086775 SWITCH LAMP
W0086833 WESTINGHOUSE FRIDGE DOOR BOTTOM HINGE PLATE R/H
W0087161 TRAY EGG
W0087213 HINGE TOP RH
W0087464 ROLLER REAR GREY
W0087741 LAMP 25W SES BLUE 240V E14
.JPG)
W0088096 MOTOR FAN EVAP
W0088199 HEATER DEF & DTT R600A 790W
W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL
W0018042 BRACKET FAN MOTOR
$7.00
W0018049 CLIP SELF ADHESIVE
$9.00
W0018078 SHROUD FAN MOULDED
$16.30
W0018166 GROMMET FAN MOTOR
$16.45
W0018170 GROMMET COMPRESSOR
W0018253 CAP CORNER WHT
$17.05
W0018254 CAP CORNER GREY SYD1212A
$23.80
W0018298 COVER HANDLE RH TOP LH BOT
$13.90
W0018299 COVER HANDLE LH TOP RH BOT
$13.90
W0018317 DOOR ASSY FIP FC RH WTM5200WB
$267.90
W0018318 DOOR ASSY FZR RH WH WTM5200WB
$226.00
W0018383 GASKET LAMP SEALING
$7.70
W0018470 COVER EVAPORATOR ASSY
W0018477 EVAPORATOR HEAT SHIELD COVER
$16.50
W0018624 PAN DRAIN WANBAO ETZ110
$21.10
W0081199 TIE CABLE 140MM LONG
W0081263 PIN COMPRESSOR MTG RS652M*6
W0082722 FOAM TAPE RJ393V
W0082742 CAP SCREW WHT
W0083869 PLUG DRAIN WHT
W0084558 DAMPER NOISE
W0084749 CLAMP-CORD BJ385T
W0085341 BAFFLE CASING
W0085343 BAFFLE MANUAL CONTROLLED
W0085376 AIR CURTAIN RJ393V
W0085390 EPS CONTROL DEL AIR RJ362V
W0085461 KNOB LOCK
W0085462 LOCK LATCH
W0085494 INSULATION EVAP COVER RJ523V
W0085533 DOOR DAIRY RH RJ523V
W0085580 SKID CRISPER DELI BIN RJ393V
W0085599 SPACER ROLLER STRIKESIDE RJ393
W0085630 SEALING MF RJ393V
W0085654 ROLLER CRISPER LID
W0085702 ROLLER ADJUSTABLE RJ393V
W0085947 PLUG SCREW
$3.90
W0086010 BIN BOTTLE RJ523V
W0086013 FINGERS BOTTLE
W0086053 THIMBLE FILLER ASSY CLOSED
W0086056 THIMBLE CAM ASSY CLOSED RJ393V
W0086078 RUNNER CENTRE
$55.00
W0086339 SCREW M4 X 8 MUSH RJ393V
W0086441 GASKET DEL TOP N280J
W0086579 TAPE FOAM SEALING SBM3800MA
W0086648 SHELF FC 699.92MM X X386.89MM
W0086996 SHIELD LAMP
W0087012 BIN CRISPER RH
$76.90
W0087023 HOUSING CONTROL TOP
W0087025 AIR CURTAIN
W0087026 AIR CURTAIN LID
W0087168 PAN DRAIN
$24.95
W0087175 GASKET DELIVERY FRONT
W0087189 LENS LIGHT FT527SA
W0087334 PAD STOP SKID ROLLER
W0087402 SCREW 8/32 X 3/8 ETM3600WB
W0087403 CLIP MOUNTING COMPRESSOR
W0087405 SCREW 12/14 16MM ETM3600WB
W0087406 SCREW-HINGE/CAM-BTM ETM3600WB
$4.50
W0087407 SCREW 8/32 X 1/2THREAD FORMING
W0087409 SCREW EVAP COVER 8 X 1/2
$4.00
W0087410 SCREW DELI RUNNER RJ393V
W0087411 SCREW HINGE CENTRE
$4.50
W0087412 SCREW ETM3600WB
W0087416 SCREW 8 X 1/2 T/F ETM3600WB
W0087417 NUT ETM3600WB
W0087418 SCREW 8 X 19 T/CT TBT
$5.50
W0087422 LOCK WASHER ESE6108WA
W0087477 HINGE CENTRE N280J WHITE
W0087496 HINGE DOOR CENTRE GREY
W0087497 CAP SCREW GREY
W0087594 BASE PLATE COMP ASSY STM5200WA
W0087652 GASKET DOOR FZR
W0087654 GASKET DOOR FC
W0087705 SHELF ASSY FZR
W0087720 COVER EVAP WTM5200PA
W0087727 LID CRISPER ASSY
W0087737 TROUGH DRAIN ASSY KTM5200WA
$24.95
W0087822 SHAFT ROLLER
$7.00
W0088006 EVAP ASSY R600A ETM5200SC
W0088045 RUNNER DELI DEEP RH
W0088054 BIN DAIRY
W0088180 LAMPHOLDER & HARNESS FZR
$44.90
W0088182 CORD SERVICE INSULATED R600A
W0088186 CAPAC 4UF 400V 2 WIRE CLIP IN
W0088230 CTRL BRD ERF450 & KIT ASSY
W0088349 TRAY ICE CUBE ASSY
W0088653 SEAL BY PASS WTM5200
W0088782 COVER COMPRESSOR
$14.90
W0088913 COMPRESSOR KIT-WANBAO ETZ110
W0163904 KNOB ICE B6565WTB2800WA-XAU
W0166429 SPRING ICE CUBE TRAY
