WTB5404SA — 925060010 00
WESTINGHOUSE — Fridge
Parts for WTB5404SA
.JPG)
W0018582 BADGE NAMEPLATE
W0020667 PCBA 3 LEDS CLUSTER GALAGA
W0020674 TERMINAL BLOCK TH1116Y
W0027096 BOARD G SSLB WBE4500SA
$179.85
W0027433 CAPACITOR 4UF
$14.90
W0027439 SCREW TRILOB M5X16
$4.50
W0027522 COVER SCREW
$4.50
W0027529 GROMMET FAN SIDE
$8.75
W0027532 MOTOR FAN L 240V/50HZ 350MM TY
W0027540 SHROUD FAN
$55.00
W0027560 GROMMET COMPRESSOR
$11.50
W0027562 CLAMP NTC EVAPORATOR
W0027610 CLAMP COMPRESSOR
$4.50
W0029335 COVER EVAP ASSY TF80 WH/KL
$34.15
W0029461 DRAWER CRISPER BODY TF80
.jpg)
W0029560 HEATER RAD DEF R600 240V TF80W
W0029587 HARNESS-ASSY SENSOR DEFROST
W0029699 FOOT BASE THREAD
$8.75
W0029701 FOOT LEVER
W0029735 HANDLE RH ASSY
W0087752 BLADE FAN
W0154018 PCB ERF1600 PROGRAMED WTB4604
W0018166 GROMMET FAN MOTOR
$16.45
W0020669 LENS 3 LEDS CLUSTER GALAGA
$26.80
W0020681 CLAMP CABLE JIAX-C
$4.50
W0020682 TERMINAL COVER JIAX-C
$9.00
W0027461 BIN ICE COOL MINT
W0027539 BRACKET MOUNT FAN SURROUND
$14.50
W0027598 GASKET FZR TF80
$106.75
W0027600 GASKET FC TF80
$120.00
W0029309 HINGE TOP RIGHT
$8.65
W0029333 DUCT EVAPORATOR
$96.00
W0029373 SUPPORT EVAPORATOR LEFT TF
$6.20
W0029398 DOOR BIN LOCKABLE TF80 WH ASSY
W0029406 DOOR BIN FLEX 80 WH-HOTFOIL
W0029412 DOOR BIN FC SHALL 80 WH-HOTFOI
W0029431 DOOR BIN FC BOTTLE TF80 WH
W0029433 DOOR BIN FINGER TF80 WH
$9.00
W0029439 SHELF FZR TF80 ASSY
$79.00
W0029444 MULTIFLOW ASSY LED TF
$105.25
W0029446 SHELF FC TF80W
$79.80
W0029450 SHELF FC TF80W WH ASSY DELI
W0029464 DIVIDER DRAWER TF WH ART
W0029465 COVER TOP HINGE RIGHT GR
$4.50
W0029536 BEARING AUTO CLOSER R TF SL
W0029565 BEARING HINGE FC TOP TF SL R
$10.90
W0029567 BEARING HINGE FZR TOP CLOSED
$8.15
W0029582 SUPPORT SHELF DOUB T&S TF
$14.30
W0029584 DOOR BIN FZR DIVIDER
W0029597 PAN DRAIN DYN CON
W0029599 TWIST&SERVE 2 ICETRAY KIT TOP
$82.70
W0029603 REAR HOUSING PCB COVER
$164.80
W0029604 REAR HOUSING PCB ADAPTER
W0029608 DRAWER C/COVER TF80 WH ASSY
W0029616 DRAWER CRISP FRONT TF80 WH ASY
W0029668 TRAY EVAP DRAIN TF80W
$18.00
W0029674 HINGE CENTRE BASE ASSY
$37.75
W0029675 HINGE CENTRE PIN SWING DOOR
$8.15
W0029697 COVER FOOT LEFT HINGE GREY
$12.95
W0029702 HINGE BASE RIGHT ASSY
W0029708 FOOT LEFT ASSY
$20.10
W0029740 DRAWER DELI FC HALF WH ASSY
$77.25
W0029772 DISPLAY UI WH 1ZONE EXT ASY
$195.00
W0029830 SUPPORT EVAPORATOR RIGHT TF
$6.20
W0029842 TUBE CORRUGATE TF
$16.95
W0029906 EVAPORATOR FF TF80 N
$95.75
W0029926 CRISPER GASKET 80
$22.00
W0030210 DOOR PACKED FZR+FC WTB5404SA-R
W0030345 DOOR BIN FZR TF80 WH-HOTF-ART
W0086608 CORD SERVICE INSULATED
W0147391 COMPRESSOR JIAX TH1116Y
W0147520 SWITCH DOOR
$26.50
W0147552 ROLLER REAR WTB4600WA RAYONG
$7.20
W0147553 SHAFT ROLLER
W0154026 LENS COVER BLUE ASSY
$27.50
W0284102 SEAL FOAM
$8.70
