WTB3400PC — 925053042 00
WESTINGHOUSE — Fridge
Parts for WTB3400PC
W0027417 RACK WINE
W0027422 COVER DEODORIZER WHITE
$4.50
W0027432 HARNESS THERMO FUSE
W0027433 CAPACITOR 4UF
$14.90
W0027439 SCREW TRILOB M5X16
$4.50
W0027460 BIN ICE
W0027462 SUPPORT ICE T&S
$15.50
W0027465 TRAY CHILL ROOM 60W L
$86.95
W0027468 LID CHILL ROOM 60W
W0027477 CRISPER HANDLE TF 60W
W0027484 TRAY EGG
$11.90
W0027507 GEAR CONTROL TEMP
$18.30
W0027521 LENS MULTIFLOW TF
$7.00
W0027522 COVER SCREW
$4.50
W0027529 GROMMET FAN SIDE
$8.75
W0027540 SHROUD FAN
$55.00
W0027559 CLAMP DRYER
$4.50
W0027560 GROMMET COMPRESSOR
$11.50
W0027561 CLAMP NTC EVAPORATOR
$4.50
W0027567 HEATER DEFROST R600A 240V
W0027577 RAIL DOOR SUPPORT 60W WHT
$9.35
W0027585 GASKET FZR TF60W 549 X 471
$90.00
W0027590 GASKET FC TF320L 549 X 1036
$101.55
W0027608 COVER TOP CABINET WH GR
$6.95
W0027610 CLAMP COMPRESSOR
$4.50
W0027617 HINGE CENTRE RIGHT
$40.50
W0027618 HINGE TOP RIGHT
$37.50
W0087752 BLADE FAN
W0147528 HARNESS MULTIFLOW TF BASIC
W0147530 TRAY TWIST AND SERVE ASSY ICE
W0154347 WESTINGHOUSE FRIDGE DOOR HINGE CONVERSION KIT
W0018166 GROMMET FAN MOTOR
$16.45
W0027412 BAFFLE SLIDE FZR TF WHITE
$4.00
W0027424 HARNESS EARTH
$17.60
W0027426 SWITCH DOOR TF DOUBLE
$20.00
W0027428 POWERCORD REFRIGERATOR AU
W0027431 LAMP 15W 240V E14
W0027437 CABLE TIES 2.5X120
$4.50
W0027438 SCREW COUNTERSUNK M4.8X19
$4.50
W0027441 SCREW TRUSS 4.2X13
W0027442 SEAL FOAM EVC SEALER
$7.45
W0027443 SEAL FOAM 6X8
$7.70
W0027463 SHELF FZR 60W ASSY
W0027470 SHELF FC ASSY 60W
$60.40
W0027472 COVER CRISPER ASSY 60W
W0027474 KNOB HUMIDIFIER
$15.95
W0027478 CRISPER BODY TF 60W
$94.00
W0027480 CRISPER FRONT TF 60W
W0027485 BIN DOOR
$55.95
W0027486 BIN DOOR HALF WIDTH
$41.00
W0027491 BIN DOOR BOTTLE WH ASSY 60W
W0027493 BIN DOOR
$66.55
W0027503 HOUSING MAIN PCBA TF
$24.40
W0027504 LOCK HOLDER LAMP
$4.50
W0027508 SLIDE CONTROL TEMP
$26.50
W0027520 LENS FREEZER TF
$4.50
W0027534 DUCT MULTIFLOW TF LARGE
$21.90
W0027536 COVER MULTIFLOW FRONT BAS TF L
W0027539 BRACKET MOUNT FAN SURROUND
$14.50
W0027542 DUCT EVAPORATOR REAR TF
$22.95
W0027543 COVER EVAPORATOR FRONT TF
$12.90
W0027556 PAN DRAIN WATER HXK
$24.90
W0027563 COVER HEATER R600A
$14.90
W0027565 SUPPORT HEATER TF R600A
$28.00
W0027566 RETAINER THERMAL FUSE
$9.00
W0027568 EVAPORATOR 7 PASSES 6.5
$125.95
W0027570 TUBE SUCTION EXTENSION WANBAO
$17.60
W0027575 TUBE DISCHARGE EXTENSION WANBA
$17.60
W0027583 COVER HANDLE POCKET WH GR
$11.00
W0027606 BEARING AUTO CLOSER R
$10.20
W0027612 COVER HINGE TOP COVER RIGHT GR
W0027614 HINGE TOP COVER LEFT GR
$33.00
W0027616 HINGE BOTTOM BASE RIGHT
$37.50
W0077734 TUBE FILLER
W0085339 DRIER REFRIGERATION 280 LTR
W0087781 SPRING TWIST&SERVE
W0096152 TRAY ICE CUBE
W0096153 KNOB ICE T&S WHITE
W0147305 PAN DRAIN WATER WANBAO ETZ
W0147320 COMPRESSOR WANBAO ETZ95
W0147486 DEODORIZER NANO COPPER
W0147493 DOOR FOAMED FZR TF60W W GR
W0147510 DOOR FOAMED FC TF320 W GR
$93.00
W0147521 BOARD MAIN ERF 1500 TF BASIC
W0147529 SCREW TRILOB M3X10
W0147531 FRAME ICE T&S
W0147535 MOTOR FAN 240V/50HZ
W0147538 PAN DRAIN WATER JIAXPERA
W0147540 COMPRESSOR KIT JX NS1114Y
W0147541 COMPRESSOR ACC HXK95AA
W0147549 FOOT BASE HINGE
W0147554 BASE COMPRESSOR 60W
W0147555 FOOT LEVER
W0147557 FOOT BASE
