WHE6000SB — 925060879 03
WESTINGHOUSE — Fridge
Parts for WHE6000SB
W0368023 CLAMP NTC EVAPORATOR
$4.50
W0368416 FAN, ASSEMBLY, FREEZER, 2.7W,2700RPM
$139.00
W0368433 MOTOR FAN DC 3W
W0368451 EXTENSION,SLIDE,LEFT
$57.00
W0368452 SLIDE EXTENSION ASSEMBLY RIGHT HAND 300MM
$57.80
W0368463 SENSOR,HARNESS,DEFROST
$28.00
W0368523 BIN ICE PACIFIC CLEAR
$39.00
W0368546 COVER CRISPER ASSY MD90 WH
$119.50
W0370706 HUMIDITY SENSOR
$18.00
.jpg)
W0371547 DAMPER, WITH, MOTOR
$99.00
.jpg)
W0373500 HEATER FLIP MULLION MD
$117.00
W0365667 HINGE,COLUMN,LOWER
$3.50
W0365693 BADGE 16X75.5 MM WESTINGHO
$12.00
W0365721 COMPRESSOR JAIX VNX1113Y
W0365795 GEAR
$12.00
W0365812 DAMPER, COMPRESSOR, 28.6MMX17MM
$14.00
W0365942 GROMMET FAN MOTOR
W0366097 SPRING,HINGE,COLUMN
$11.00
W0366169 SENSOR,MAGNET,DOOR,15.7X12.7MM
$47.00
W0366316 LENS,LED PCB,SIDE,116.02X50.5M
$21.00
W0366931 PCBA VSCC FLEX 1
$221.00
W0367948 CLIP,RETAINER
$3.50
W0367952 FIXING BRACKET,COMPRESSOR,42X2
$3.50
W0368006 BOLT, FOOT, M5X16 PH
$3.50
W0368009 CLAMP COMPRESSOR
$4.50
W0368021 SCREW TRUSS 4.2X13
$5.50
W0368330 HEATER,DEFROST,240V,197W
$109.00
W0368332 COLUMN,FRIDGE DOOR,ASSEMBLY,91
$125.00
W0368379 BEARING AUTO CLOSER L TF DG
$11.00
W0368380 BEARING AUTO CLOSER R TF SL
W0368381 GUIDANCE RAIL,DRAWER,LEFT
$227.00
W0368382 GUIDANCE RAIL,DRAWER,RIGHT
$265.00
W0368404 SHROUD FAN BF
$90.00
W0368469 LEVER,FOOT
$10.00
W0368529 EXTENSION SLIDE INSERT FZR RH
$12.00
W0368530 EXTENSION SLIDE INSERT FZR LH
$12.00
W0368787 DOOR SPARE FC L+R WHE6000SA-D
$667.00
W0368860 LED PCB
W0368892 BIN DOOR FINGER MD90 ASSY
$57.00
W0368949 BIN,DOOR,COMPLETE,LOCKABLE
$24.00
W0368983 SCREW, 8GX1/2
W0369887 PCB, LED, SIDE, L=342MM
$40.65
W0369973 AIR CHANNEL,ASSEMBLY
$172.00
W0370024 BRACKET, ICE-MAKER
$15.00
W0370028 SUPPORT BRACKET, SLIDE
$21.00
W0370030 TUBE,JUMPER,6.35MM
$12.20
W0370035 RAIL,SHELF,TELESCOPIC RAIL
$28.00
W0370059 TUBE COIL WATER TRAY PRI MD90
$17.35
W0370090 DRAIN PAN MD & HEATER
$31.00
W0370092 DRAIN PAN & HEATER TUBE ASY L
$25.50
W0370186 COVER,EVAPORATOR,ASSEMBLY
W0370225 HEAT PIPE,DRAIN,PAN OVER FLOW
$18.20
W0370401 FILTER,DRYER
$22.50
W0370571 SWITCH,DOOR,REED
$8.00
W0371100 CONFIGURED ELECTRONIC, ERF2003 15W FCT
$217.90
W0371446 COVER,FOOT,LEFT
$14.00
W0371448 BASE,FOOT
$10.00
W0371464 COVER GRID AIR RETURN BF
$4.00
W0371471 GASKET FRZ BF80
$150.00
W0371482 ADJUSTABLE FOOT,ASSEMBLY
$12.00
W0371560 DOOR SPARE FZR WH WHE6060SB
$431.00
W0371714 DAMPER,FAN MOTOR,EVAPORATOR
$8.00
W0372297 WASHER SLINGER NYLON
$4.50
W0372322 CAP,SCREW COVER,RIGHT,20.8MM
$3.50
W0372335 COVER,MAGNET,END CAP
$3.50
W0372362 COVER FOOT RIGHT HINGE DG
$3.50
W0372369 SCREW 6X20 SELF TAPPING
$4.00
W0372378 CENTRE HINGE PIN DRAWER DOOR
$3.50
W0372382 TUBE,NOTCH
$3.50
W0372387 SCREW-HINGE/CAM-BTM ETM3600WB
$4.50
W0372389 CAP,SCREW COVER,LEFT,20.8MM
$3.50
W0372405 SPACER,DAMPER,3-WAYS
$3.50
W0372467 SUPPORT EVAPORATOR BF
$4.95
W0372551 HINGE,TOP,LEFT
$8.00
W0372563 COVER TOP HINGE IW LH DG
$9.00
W0372577 SHAFT,ROLLER
$9.00
W0372579 BEARING,HINGE,TOP
$9.00
W0372590 HINGE,TOP,RIGHT
$10.00
W0372728 SUPPORT PASTRY SLIDE RH
$16.00
W0372753 EVAPORATION TRAY
$15.50
W0372766 EGG HOLDER
$19.00
W0372768 COVER,LENS,ASSEMBLY,385.4X90.4
$16.60
W0372822 TUBE PROCESS
$21.00
W0372826 BEARING,PAD,TELESCOPIC RUNNER
$21.00
W0372830 FOOT,LEFT
$22.00
W0372831 FOOT,RIGHT
$22.00
W0372992 BRACKET ADJUSTMENT BF IDP RH
$30.50
W0373000 BRACKET ADJUSTMENT BF IDP LH
$31.00
W0373068 WIRING,SENSOR,AIR CHANNEL
$41.00
W0373078 HINGE,MIDDLE
$40.00
W0373159 POWER CORD INV AU/NZ FERITE
$49.00
W0373218 DOOR SHELF
$68.00
W0373277 DRAWER FRONT MD90 WH ASSY
$72.00
W0373290 DRAWER LOWER BODY FZR
$65.00
W0373295 BIN DOOR FLEX 80 1-HOTFOIL
$72.00
W0373413 GLASS SHELF,REFRIGERATOR
$99.00
W0373414 RACK,BOTTLE
$94.00
W0373438 DRAWER, FZR MID ASSY 90
$95.00
W0373445 EVAPORATOR
$99.00
W0373547 GASKET, REFRIGERATOR DOOR
$133.00
W0373684 VALVE DRAIN ASSY BF
$195.00
W0373767 USER INTERFACE BOARD,ASSEMBLY
$279.00
W0373809 HANDLE ASSY MD90 WEST/HOUSE
$310.00
W0375286 DRAWER,PASTRY TRAY,MD 90
$44.00
W0375422 DRAWER FZR MID ASSY 90
$68.00
