RJ332V
WESTINGHOUSE — Fridge
Parts for RJ332V
W0018079 HEATER DEFROST
W0018095 BIN DOOR FZR
$50.00
W0018098 BIN HALF WIDTH
W0018102 BIN CRISPER ASSY LARGE
.JPG)
W0018109 COVER HINGE RH
W0018129 BIN DELI SHALLOW
W0019131 SCREW COUNTER SUNK THIMBLE
$4.50
.JPG)
W0083263 STOP DOOR
.JPG)
W0084321 BLADE FAN
.JPG)
W0085600 CAP LEG
$12.90
W0085609 LEG STABILISING
W0085616 LAMP 25W SES E14 HD BLUE 240V
W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL
W0018042 BRACKET FAN MOTOR
$7.00
W0018049 CLIP SELF ADHESIVE
$9.00
W0018081 SHROUD FAN MOULDED RJ393V
W0018125 COVER HINGE LH
$12.95
W0018126 RUNNER LH
W0079752 GROMMET RUBBER COMP FR121F
W0079756 CLIP MTG PIN COMP RS652M*6
W0080631 CORD SERVICE AUSTRALIAN C195F
$15.30
W0081178 CAP CORNER MODEL C300F/C302F
W0081199 TIE CABLE 140MM LONG
W0081263 PIN COMPRESSOR MTG RS652M*6
W0081362 SWITCH LAMP C195F/P330F
W0081396 CAP SNAP C195F
W0082523 RIVET
W0082722 FOAM TAPE RJ393V
W0082728 SPACER-HINGE C300C
W0082742 CAP SCREW WHT
W0083073 SCREW HINGE/CAM-BTM
W0083078 WASHER-HINGE-CENTRE RE521Q
W0083101 SHAFT ROLLER
W0083235 CLIP-HEATER-ALUMINIUM BJ414Q
W0083869 PLUG DRAIN WHT
W0084170 SPACER REAR (BUMPER) N520F
W0084173 GROMMET FAN MOTOR
W0084504 CAPAC 4*0UF 400V WIRED CLIP
W0084558 DAMPER NOISE
W0084602 TUBE DRAIN RJ393V
W0084619 STICKER MAX 25 WATTS N280J
W0084654 SCREW HINGE CENTRE N520SF
W0084749 CLAMP-CORD BJ385T
W0085056 TIMER DEFROST 8HR N520F
W0085140 PVC TUBE BLUE 80MM N300H
W0085158 WASHER ZINC PLATE RJ526V
W0085261 HINGE REAR SPACER(BUMPER)N520H
W0085283 DOOR ASSY FIP FC RH RJ332V
W0085284 DOOR ASSY FIP FZR RH RJ282V
W0085285 HEAT SHIELD RJ302V
W0085286 INSULATION EVAP COVER N280J
W0085293 EVAPORATOR COVER RJ282V
W0085304 GASKET FZR DOLPHIN GREY RJ282V
W0085314 GASKET FC DOLPHIN GREY RJ332V
W0085340 EPS HOUSING CONTROL REAR RJ362
W0085341 BAFFLE CASING
W0085342 LENS LIGHT
W0085343 BAFFLE MANUAL CONTROLLED
W0085344 HOUSING CONTROL TOP DEC RJ393V
W0085374 EPS AIR CURTAIN LID RJ393V
W0085375 EPS AIR CURTAIN RJ393V
W0085390 EPS CONTROL DEL AIR RJ362V
W0085458 DOOR DAIRY RH RJ282V
W0085460 DOOR DAIRY LH RJ282V
W0085461 KNOB LOCK
W0085462 LOCK LATCH
W0085467 EVAPORATOR ASSY RJ282V
W0085483 BASE PLATE COMPRESSOR RJ332V
W0085489 SHELF FZR
W0085499 SHELF FC 505.47MM X 334.79MM
W0085518 BIN CAN RJ282V
W0085543 BIN DAIRY RJ282V
W0085559 COVER CRISPER ASSY RJ282V
W0085576 CONTROL HUMIDITY
W0085579 ROLLER ASSY CRISPER LID
W0085580 SKID CRISPER DELI BIN RJ393V
W0085583 DIVIDER CRISPER RJ393V
W0085590 RUNNER DELI SHALLOW RH
W0085593 COVER EVAPORATOR ASSY RJ282V
W0085598 HINGE PLATE BOTTOM RH BLACK
W0085599 SPACER ROLLER STRIKESIDE RJ393
W0085614 PRE COOLER RJ282V
W0085625 HINGE PLATE BOTTOM LH BLACK
W0085626 HARNESS TIMER RJ282V
W0085628 GASKET DELIVERY TOP RJ393V
W0085629 GASKET DELIVERY FRONT RJ393V
W0085630 SEALING MF RJ393V
W0085639 DEFROST TERM THERMO RJ282V
W0085649 COVER HANDLE RH TOP DR RJ395V
W0085650 COVER HANDLE LH TOP DR RJ395V
W0085651 SEAL BYPASS PLASTIC
W0085654 ROLLER CRISPER LID
W0085655 HOUSING ROLLER WHEEL RJ393V
W0085660 HINGE TOP RH
W0085661 HINGE TOP LH
W0085666 BRACKET PRE COOLER RH RJ393V
W0085667 BRACKET PRE COOLER LH RJ393V
W0085668 TRAY DEFROST WATER RJ393V
$28.75
W0085685 HOUSING CONTROL REAR RJ362V
W0085686 NAMEPLATE WHOUSE OPHIR
W0085689 TROUGH DRAIN ASSY RJ282V
W0085690 NOISE DAMPER RJ282V
W0085702 ROLLER ADJUSTABLE RJ393V
W0085703 COM R134A ECR55HLP EMBRACO
W0085850 RELAY PTC STARTER 220MD3
W0085853 SCREW NO 8 X 1/2 PAN HD RJ393V
W0085858 HINGE CENTRE RJ393V
W0085861 THERMAL FUSE ASSY RJ282V
W0085866 LAMPHOLDER & HARNESS RJ393V
W0085867 COVER ELECTRICAL EMB ECU60
$32.00
W0085947 PLUG SCREW
$3.90
W0085954 DOOR ASSY FIP FC LH RJ332V
W0085955 DOOR ASSY FIP FZR LH RJ282V
W0085975 SCREW THREAD FORMING
W0086012 BIN BOTTLE RJ282V
W0086015 BOTTLE FINGER RJ282V
W0086053 THIMBLE FILLER ASSY CLOSED
W0086056 THIMBLE CAM ASSY CLOSED RJ393V
W0086078 RUNNER CENTRE
$55.00
W0086079 SHIELD LIGHT
$6.60
W0086134 TRAY ICE CUBE RJ393V
W0086135 LID BIN ICE CUBE RJ393V
W0086136 BIN ICE CUBE RJ393V
W0086137 SCREW DELI RUNNER
W0086324 TRIM SHELF FZR 461MM
W0086339 SCREW M4 X 8 MUSH RJ393V
W0086349 UTILITY BIN DEC LH RJ302V
W0086352 RUNNER DELI SHALLOW LH
$11.90
W0086379 SCREW BASE PLATE RJ393V
W0086383 THERMOSTAT CONTROL
W0086385 OVERLOAD ECR55 RJ282V
W0086395 KNOB CONTROL
$16.00
W0086398 MOTOR FAN EVAP RJ523V
W0086456 PAN DRAIN SR300B
W0087463 ROLLER REAR
W0111207 NUT RJ522Q
W0134832 TAPE-FOAM SEAL18X4 14M/RLL.
W0138446 SCREW & WASHER C195F/RS652M*6
W0139540 SCREW. EARTH TAG RJ522Q
