WFG617SANG — 940001832 28
WESTINGHOUSE — Cooker Gas

W0011123 BURNER GRILL

W0011297 BLADE FAN

W0011319 COVER GRILL DISH

W0011404 TRAY SCONE

$19.90

W0011899 IGNITOR OVEN BURNER

W0011922 HANDLE DOOR

$32.10

W0011995 NUT M6 LH FAN MOTOR

W0012326 CLIP MOUNTING ELEMENT

W0012570 END CAP HANDLE BLK WEST NGD

$14.05

W0012990 SPACER HANDLE BLK FRESCO

$10.25

W0013199 SHELF OVEN

W0013702 TIMER 120 MINUTE WESTLAKE

W0013859 KIT SWITCH TOGGLE BLACK

W0013860 SWITCH KIT MOMENTARY BLK

W0014040 SCREW 3/16X28 PAN PH TRILOB ZY

W0022617 BURNER CROWN RAPID CYLINDER

W0022624 BURNER CROWN AUX CYLINDER

W0022807 HINGE DOOR OVEN

W0027342 GRILL DISH GIO ENAMEL

$105.45

W0027351 BURNER CAP RAPID MATT BLACK EN

W0027390 IGN BOX 6P - 220.240V JAVA

W0029488 GRILL GRABBER FORTE

$4.50

W0029889 PNL OUT OV DR ASY 600FC SS WES

W0032275 LAMP 25W 240V G9 PYRO HALOPIN

W0042758 SPARK PLUG GRILL DERLITE

W0046406 CLIP MOUNTING ELEMENT

W0050403 MOTOR FAN OVEN

W0057757 T'STAT COPRECI 1000 MM COAX

W0057776 THERMOCOUPLE 540 OVEN BURNER

W0147339 SEAL OVEN MODULAR PROFILE

W0275063 LAMP OVEN ROUND PYRO BIOS

W0283367 T'COUPLE TT ELUX BURNER 275

W0283368 T'COUPLE TT ELUX BURNER 500

W0011264 PLATE CVR TERM ELEC BIOS

$13.85

W0011323 COVER OVEN BURNER

$73.75

W0011374 BRKT IGNITION GRILL H/T 540

$12.60

W0011383 BRACKET SUPPORT GRILL BOX R/H

$14.30

W0011384 BRACKET SUPPORT GRILL BOX L/H

$14.30

W0011389 BRACKET STABIL. BOLT ASSY FRES

$19.85

W0011454 PNL OUT GR DR ASSY 600 SM SS

$192.90

W0011523 PANEL COVER WIRE 600 S/G FRESC

$39.10

W0011630 PANEL CONTROL SCREEN WFG617SA

$175.00

W0011700 PANEL SPLASHBACK 600 SS FRESCO

$36.95

W0011845 HINGE GR DOOR 540 FRESCO PH2

$7.70

W0011846 HINGE GR DOOR 540 FREE FRESCO

$53.85

W0012082 FLUE DUCT OVEN 540 GAS BIOS

$6.05

W0012401 INJECTOR AUX LP 0.62

W0012403 INJECTOR 1.75 ELUX WOK NG

$8.80

W0012417 SUPPORT COUNTER FRESCO

$7.05

W0012521 SCREW M4 X 4 PAN #1PH SMALL HD

$4.50

W0012748 HOLDER INJECTOR OVEN

$10.45

W0012778 CORD SERVICE 10A

$10.05

W0012880 GLASS OV DR INNER 600 FRESCO

$96.35

W0012913 CANOPY GRILL GAS FF FRESCO

$27.50

W0013025 REGULATOR GAS NG INTEG TEST PT

W0013263 SHIELD SPILLAGE

$17.45

W0013342 INSUL GRILL CANOPY TOP FRESCO

$14.30

W0013446 JET BYPASS COPRECI 0.73

$8.30

W0013467 OVEN BRACE 600UP ASSY FRESCO

$24.85

W0013587 SHUTTER AERATION GRILL NG BIOS

$6.25

W0013603 THERMOCOUPLE 540 GRILL BURNER

$44.90

W0013628 TRIM DOOR TOP VENT 600 FRESCO

$31.90

W0013897 INSTRUCTION GAS CONVERSION

W0013989 GRILL INJECT BLOCK FF FRESCO

$13.20

W0014022 SCREW #10-16X5/8 PAN PH2 BLK

$4.50

W0014026 SCREW #8 X 5/16 CSK #2PH AB BK

$4.50

W0014028 SCREW NO 8 X 8MM W/HD PD NI

$4.50

W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK

W0014030 SCREW #8 X 8MM HEX/MULTI

$4.50

W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK

$4.50

W0014064 CLIP BULB THERMOSTAT GAS (4MM)

$10.00

W0014129 SCREW M4 X 16MM HEX ZC

$4.50

W0021433 FOOT TRIVET

$7.05

W0021525 SCREW M4 X 15 HEX ZC

$4.50

W0021774 HOB ASSY GAS S/S 600 FF FC WES

$280.45

W0022171 FOOT LEVELING

$16.35

W0022627 BURNER CAP MATTE SEMI-R CYLIND

$22.35

W0022628 BURNER CAP MATTE AUX CYLINDER

$22.35

W0029625 PLUG SPARK WOK 900MM ENAMELLED

W0029628 PLUG SPARK 600 MM ENAMELLED

W0029629 PLUG SPARK 900 MM ENAMELLED

W0029662 ANTI TILT PLATE

$15.65

W0029802 TUBE OVEN SUPPLY 600SI FRESCO

$24.20

W0029831 BRACE LOWER 600UP

W0029884 WIRE HIGH VOLTAGE WFG617 650MM

$14.50

W0029885 WIRE HIGH VOLTAGE WF617 1100MM

$16.50

W0029960 F/FRONT PAINT 600FC FRESCO S/G

W0030071 CLIP SPARK PLUG ELUX MO/A 120

W0030387 KNOB ASSY SILVE WEST GAS FRSCO

W0030426 PIPE MANIFOLD ASS 540R SG FF

W0030443 BURNER BODY ASSY AUX IGN NG

$43.00

W0030447 BURNER BODY ASSY S/RAP IGN NG

W0030451 BURNER BODY ASSY RAPID IGN NG

W0035498 BURNER OVEN COMP ASSY 540 BIOS

W0035788 DEFLECTOR HEAT GRILL UC20

W0038742 BRACKET MOUNTING GRILL UC20

W0041124 PANEL FAN COVER GAS ENAM BIOS

W0041134 PANEL KICK 600 RFP FRESCO

W0045366 WASHER R-FIT SWITCH FRESCO

$4.50

W0046663 TRIVET STD/WOK FC 600 FRSCO

W0046720 NIPPLE INJ OVEN 1_60MM NG

W0046736 INJECTOR 1.00 H/P

$8.80

W0046737 INJECTOR 1.35 H/P

W0053308 STICKER GAS TYPE NG

$4.00

W0054664 INSULATION OVEN CABINET

W0065406 SCREW #8 X 3/4 STEPPED PAN BLK

W0065458 NUT HEX M6

$4.50

W0105318 SCREW

$7.35

W0109046 SCREW TORQ #4 X 12 #6 PAN HEAD

W0110088 BURNER ASSY TRIPLE CROWN WOK

W0154046 SLIDER GRILL DOUBLE ACTION LH

$44.00

W0154047 SLIDER GRILL DOUBLE ACTION RH

$44.00

W0274177 PANEL SIDE GREY PRE PAINT

$54.10

W0282402 BRACKET F/FAIL GAS RAIL FRESCO

W0283106 GASKET VALVE COPRICI

W0283371 T'COUPLE TT ELUX BRNR WOK 275

$50.60

W0283510 TUBE BURNER GRILL FF

W0283522 TUBE BURNER 540 L/F FRESCO FF

W0283523 TUBE BURNER 600 R/L FRESCO FF

W0283524 TUBE BURNER 540 R/R

W0283525 TUBE BURNER 540 R/F F

W0283526 TUBE OVEN SUPPLY 600SI FRESCO

W0284227 VALVE COPRECCI FSG GRILL

W0284246 VALVE COPRECCI FSG AUX

$29.45

W0284247 VALVE COPRECCI FSG SEMIRAPID

$29.45

W0284248 VALVE COPRECCI FSG RAPID

$29.45

W0284249 VALVE COPRECCI FSG TC WO

$29.45

W0365428 BURNER CROWN SEMI-RAP CYL MCH

$7.00
