POR883W — 944031378 63
WESTINGHOUSE — Cooker Electric
Parts for POR883W
.JPG)
W0011297 BLADE FAN
W0011319 COVER GRILL DISH
W0011401 DISH GRILL ENAM F/WIDTH BIOS
W0011832 HINGE DOOR OVEN PYRO
W0011995 NUT M6 LH FAN MOTOR
W0012261 ELEMENT G/BOOST 3000W - PYRO
W0012262 ELEMENT FAN RING 2200W
W0012263 ELEMENT C/HEAT 1800W NO EARTH
$95.00
W0012570 END CAP HANDLE BLK WEST NGD
$14.05
W0012988 SPACER HANDLE GLS DR NGD
.JPG)
W0013596 SWITCH THERMAL CUT OUT 190 DEG
W0013612 TRIM DOOR VENTED
W0013970 RELAY 30A SINGLE POLE 240V
W0014032 SCREW #8 X 45 PAN QUADREX
W0032275 LAMP 25W 240V G9 PYRO HALOPIN
.JPG)
W0046406 CLIP MOUNTING ELEMENT
.JPG)
W0050308 HOLDER LAMP ASSY
_1.JPG)
W0050403 MOTOR FAN OVEN
W0053514 SHELF OVEN
W0055947 LOCK DOOR ASSY
.JPG)
W0057213 SWITCH DOOR LIGHT MICRO BIOS
W0063387 ELECTROLUX WESTINGHOUSE OVEN DIGITAL CLOCK CONTROLLER KRONOS 0628001069
.JPG)
W0114461 BOARD OVC1000-SW-OVC1C301
W0011114 TERMINAL BLOCK W/EARTH BIOS
W0011264 PLATE CVR TERM ELEC BIOS
$13.85
W0011321 COVER BASE PANEL SHIELD BIOS
$29.70
W0011322 COVER HINGE DOOR PYRO LH
W0011345 BRACKET KRONOS PROBE MOUNT BIO
$12.60
W0011462 PNL DR OUT ASSY PYRO WEST WHT
$175.00
W0011666 COVER FAN & ELEMENT
$95.75
W0011857 SUPPORT ELEMENT
$12.80
W0012038 FRAME FRONT ENAM U/B PYRO BIOS
$93.50
W0012313 CLIP INSTALL RH BIOS
W0012317 CLIP INSTALL LH BIOS
$10.00
W0012319 RETAINER PYRO CATALYSER
$7.70
W0012320 CLIP TRIM DOOR PYRO
W0012322 CLIP RETAINER TRIM WH PYRO RH
$5.50
W0012323 CLIP RETAINER TRIM WH PYRO LH
$5.50
W0012632 HARNESS WIRE
W0012726 SEAL OVEN DOOR PYRO BIOS
W0012832 DOOR OVEN MID GLASS PYRO
$105.00
W0012833 DOOR OVEN INNER GLASS PYRO
W0012862 GLASS & CLIPS POR883W
$187.00
W0012974 SPACER GLASS
$8.15
W0012977 SPACER DOOR LOWER PYRO
W0013260 SHIELD WIRING
$11.95
W0013462 BRACE OVEN REAR PYRO EVOLVE
$14.30
W0013573 BRACKET INTERLOCK
$6.60
W0013574 LEVER INTERLOCK
$30.00
W0013575 BRACKET SWITCH
W0013621 TRIM PYRO FF SS LEFT
$26.40
W0013622 TRIM PYRO FF SS RIGHT
$27.50
W0013623 PLATE HINGE SGWO BIOS
W0013659 DUCT PLATE LOWER PYRO
$27.50
W0013660 DUCT PLATE MID PYRO
$16.50
W0013734 BUMPER PYRO GLASS
$4.35
W0013735 BUMPER TRIM TOP PYRO
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
W0014023 SCREW #8 X 5/8 CSK #2PH AB BK
$4.50
W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014038 SCREW 3/16X16 PAN PH TRILOB ZY
W0022974 RESISTOR 1050 OHM 20W PYRO
W0023255 SENSOR OVEN
$44.00
W0037483 PLATE MOUNTING SWITCH
W0038118 COVER RETAINING LATCH
$10.95
W0038120 COVER HINGE DOOR PYRO RH
W0038121 COVER CLEAN HEAT FULL GALV BIO
W0038822 BRACKET DECK
W0039242 TRAY BAKING PREMIUM ENAM BIOS
W0039639 BASEPLATE
W0039686 PANEL CHASSIS TOP
$27.50
W0039796 PANEL SIDE
W0039894 PANEL CABINET REAR
$27.50
W0042631 CHANNEL FRONT UB RH BIOS WELD
W0042632 CHANNEL FRONT UB LH BIOS WELD
W0042768 PLUG DOME MDP16
W0042968 HANDLE DOOR
W0048308 WIRE HARNESS KRONOS2+ GUI
W0053528 RACK INSERT ROASTING WIRE
W0053529 RACK SIDE SUPPORT OVEN EVOLVE
W0054666 INSULATION OVEN BACK PYRO BIOS
W0054667 INSULATN INSERT BACK PYRO BIOS
W0054670 INSULATION OVEN WRAP PYRO NGD
W0057222 SWITCH DOOR LIGHT ASSY PYRO
W0057755 SWITCH THERMAL CUT OUT 120 DEG
W0058491 TRIM SURROUND C/P PYRO BIOS
W0058494 TRIM DOOR SS PYRO
$24.90
W0058499 TRIM DOOR SWITCH PYRO
W0059837 DUCT PLATE TOP PYRO
W0063371 CLIP STANDOFF POWERBOARD
W0064477 SCREW CSK PH 6AB X 25MM BLK
$4.50
W0064536 SCREW #6 X 13MM HEX
W0064626 SCREW #4 X12 T25 W/HD PHIL#2
W0064627 SCREW #4 X16 T25 W/HD PHIL#2
W0065138 RIVETT POP 3.2 X 8 STL-TEXTRON
$2.80
W0065420 SCREW M4 X0.7X10 MUSH QUADRERX
W0105875 FILTER CATALYST
W0114302 MOTOR FAN COOLING
W0114491 SWITCH CHERRY
$47.90
