SWF12843 — 914900515 04
SIMPSON — Washing Machine
Parts for SWF12843
W0016638 GASKET DRUM SHAFT
$19.99
W0016981 VALVE SOLENOID 2-WAY
W0017020 PIN DOOR HINGE
$7.00
W0017025 RING LOCKING
W0017029 SPRING, BELLOW, TUB, G33
$10.50
W0017076 ELEMENT HEATING
W0017087 DISPENSER DETERGENT ASSY
W0017089 DRAWER DETERGENT
W0017199 BOLT SHOCK ABSORBER
W0017224 LOW FREQENCY ANALOG PRESSUR
W0018790 HOSE PRESSURE SENSOR L620
$4.66
W0026627 BEARING DRUM (6206Z)
W0026973 GASKET, BELLOW
W0027172 MOTOR CIM AL STK50 P69
$188.41
W0027221 HOSE DRAIN ASSY
W0027242 LOCK DOOR
W0029486 SIMPSON WESTINGHOUSE WASHING MACHINE PCB INTERFACE
W0029594 CONTROL PANEL+HANDLE PRINTED
W0048965 HOOK OUTLET HOSE
W0060454 WASHING MACHINE HOSE ASSY INLET COLD BLUE
W0075951 BELT DRIVE
W0075967 PULLEY PLASTIC
$19.25
W0147298 BUSHING HINGE
$3.15
W0015051 NUT, PLASTIC EWN14991W
$3.15
W0016559 SCREW PULLEY
$3.15
W0016881 SCREW SHELL TUB 6 5X50
$3.15
W0016906 SHOCK ABSORBER ASSY
W0016944 CAP REAR PANEL
$11.20
W0016969 TRANSIT BOLT KIT HEC54
$47.60
W0017083 SCREW COUNTERWEIGHT TOP
$2.80
W0017088 CONVEYOR ASSY
$10.99
W0017090 PARTITION DRAWER RIB
$3.99
W0017097 PUMP DRAIN LEILI
W0017098 CLAMP DET DISPENSER GASKET
W0017104 SUPPORT,HOSE DRAIN,HIGH
W0017108 SUPPORT,HOSE DRAIN,LOW
$6.13
W0017176 SPRING, TUB SUSPENSION
$8.86
W0018719 SEAL DRUM OUTER REAR
$19.11
W0018732 CORD POWER SUPPLY AUSTRALIA
$12.78
W0018746 HOSE VALVE CONNECTION+CLAMP
$7.74
W0018748 HOSE VALVE CONNECTION+CLAMP
$7.74
W0026168 SCREW, HINGE
W0026228 BEARING BALL 25X52X15
W0026970 SCREW MOTOR (8X30 TE)
$2.80
W0027062 HINGE, PORTHOLE
W0027076 FRAME, FRONT, PORTHOLE WHITE
W0027078 FRAME, BACK, PORTHOLE, GREY
W0027079 LATCH, DOOR
$6.16
W0027080 VALVE FLOATING
$28.91
W0027083 DIAPHRAGM
W0027088 DRAIN BODY INTEGRATED
$3.26
W0027094 PANEL, FRONT
$69.13
W0027095 FILTER DIAPHRAGM
$15.96
W0027098 GLASS, PORTHOLE
$94.50
W0027099 PROTECTION DOOR LOCK
$3.15
W0027108 LIFTER DRUM
$13.09
W0027122 SYPHON ADDITIVE
$3.08
W0027125 BRACKET, CONTROL PANEL
$10.01
W0027142 SPRING ON/OFF BUTTON
$5.71
W0027143 BUTTON ON/OFF
$6.51
W0027148 WORK TOP ASSEMBLY
W0027183 GASKET CONTROL PANEL
$6.16
W0027230 SUPPORT SHOCK ABSORBER
$22.40
W0027249 TUB SHELL FRONT P69
$35.67
W0027252 TUB SHELL REAR
$119.70
W0029236 AIR CHAMBER ASSY
$8.82
W0029298 COUNTER WEIGHT TOP
$30.80
W0029301 COUNTER WEIGHT FRONT
$37.14
W0029344 CROSS SPIDER ASSEMBLY
W0029348 DRUM ASSY P69/1200
$207.59
W0029602 BRACKET SPRING SUPPORT
$13.83
W0030098 PCBA MOTOR CONTROL EMC14 CIM
$143.50
W0074340 SCREW BEARING SPIDER
W0075275 CLAMP CABLE
W0075997 FOOT ADJUSTABLE ASSY
W0076221 PANEL REAR
W0076228 HINGE REINFORCEMENT
W0274078 PCBA MB EWX14 POTTED SWF12843
W0275611 WIRING HARNESS ASSY COMPLETE
$59.50
