KTM5402WA — 925060082 00
KELVINATOR — Fridge
Parts for KTM5402WA
W0020667 PCBA 3 LEDS CLUSTER GALAGA
W0020674 TERMINAL BLOCK TH1116Y
W0027433 CAPACITOR 4UF
$14.90
W0027439 SCREW TRILOB M5X16
$4.50
W0027522 COVER SCREW
$4.50
W0027529 GROMMET FAN SIDE
$8.75
W0027532 MOTOR FAN L 240V/50HZ 350MM TY
W0027540 SHROUD FAN
$55.00
W0027560 GROMMET COMPRESSOR
$11.50
W0027562 CLAMP NTC EVAPORATOR
W0027610 CLAMP COMPRESSOR
$4.50
W0029335 COVER EVAP ASSY TF80 WH/KL
$34.15
W0029435 TRAY EGG 80W
W0029461 DRAWER CRISPER BODY TF80
W0029462 DRAWER CRISPER FRONT ONLY TF80 WH ASY
W0029517 PCB PROGRAAMED KTM4602
$140.00
.jpg)
W0029560 HEATER RAD DEF R600 240V TF80W
W0029587 HARNESS-ASSY SENSOR DEFROST
W0029667 DOOR BIN FC BOTTLE TF80 EL
W0029699 FOOT BASE THREAD
$8.75
W0030069 TRAY ICE CUBE PINOT
$41.55
W0087752 BLADE FAN
W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL
W0018166 GROMMET FAN MOTOR
$16.45
W0020669 LENS 3 LEDS CLUSTER GALAGA
$26.80
W0020681 CLAMP CABLE JIAX-C
$4.50
W0020682 TERMINAL COVER JIAX-C
$9.00
W0027119 SCREW TRILOB M6X18
$4.50
W0027539 BRACKET MOUNT FAN SURROUND
$14.50
W0027598 GASKET FZR TF80
$106.75
W0027600 GASKET FC TF80
$120.00
W0029309 HINGE TOP RIGHT
$8.65
W0029333 DUCT EVAPORATOR
$96.00
W0029373 SUPPORT EVAPORATOR LEFT TF
$6.20
W0029429 DOOR BIN FLEX 1/2 TF80W EL
$84.90
W0029430 DOOR BIN FC SHALLOW 80 EL
$63.80
W0029437 SHELF FZR TF80W
$77.00
W0029446 SHELF FC TF80W
$79.80
W0029466 COVER TOP HINGE RIGHT WHT
$4.50
W0029487 MULTIFLOW ASSY KTM
$62.65
W0029535 BEARING AUTO CLOSER R TF WHT
$8.80
W0029597 PAN DRAIN DYN CON
W0029603 REAR HOUSING PCB COVER
$164.80
W0029604 REAR HOUSING PCB ADAPTER
$14.30
W0029612 DRAWER C/COVER TF80 K ASSY
W0029668 TRAY EVAP DRAIN TF80W
$16.50
W0029674 HINGE CENTRE BASE ASSY
$37.75
W0029675 HINGE CENTRE PIN SWING DOOR
$8.15
W0029695 COVER FOOT LEFT HINGE WHITE
$4.50
W0029702 HINGE BASE RIGHT ASSY
W0029703 HINGE BASE LEFT ASSY
$29.00
W0029830 SUPPORT EVAPORATOR RIGHT TF
$6.20
W0029842 TUBE CORRUGATE TF
$16.95
W0029906 EVAPORATOR FF TF80 N
$95.75
W0030237 DOOR PACKED FZR KTM5402WA-R
$311.25
W0030238 DOOR PACKED FC KTM5402WA-R
W0030345 DOOR BIN FZR TF80 WH-HOTF-ART
W0086608 CORD SERVICE INSULATED
W0088702 BADGE NAMEPLATE
$8.70
W0147391 COMPRESSOR JIAX TH1116Y
W0147520 SWITCH DOOR
$26.50
W0147552 ROLLER REAR WTB4600WA RAYONG
$7.20
W0147553 SHAFT ROLLER
W0154023 HARNESS-ASSY SENSOR KTM5402
W0284102 SEAL FOAM
$8.70
