KTM5200WB*07
KELVINATOR — Fridge
Parts for KTM5200WB*07
.JPG)
W0018080 HEATER DEFROST
.JPG)
W0018109 COVER HINGE RH
W0018222 FUSE THERMAL ASSY
.JPG)
W0018581 ROLLER ADJUSTABLE
$40.00
W0019131 SCREW COUNTER SUNK THIMBLE
$4.50
W0030867 RACK WINE
.JPG)
W0083263 STOP DOOR
W0085297 RELAY PTC STARTER
$55.00
.JPG)
W0085546 DOOR DAIRY
.JPG)
W0085600 CAP LEG
$12.90
W0085609 LEG STABILISING
W0086637 HOSE DRAIN (SLIT 130MM)
$11.90
.JPG)
W0086638 BLADE FAN
.JPG)
W0086775 SWITCH LAMP
W0086833 WESTINGHOUSE FRIDGE DOOR BOTTOM HINGE PLATE R/H
W0086834 HINGE PLATE BOT LH BLACK ASSY
$34.50
W0086839 PAN DRAIN RJ422V
W0087126 BIN CRISPER
W0087135 BIN FULL WIDTH
.JPG)
W0087142 BIN HALF WIDTH
W0087144 BIN DOOR FZR
W0087213 HINGE TOP RH
W0087214 HINGE TOP LH
.JPG)
W0087302 TIMER DEFROST 8HR ROHS 7 MINUT
.JPG)
W0087327 THERMOSTAT DEFROST TERM
.JPG)
W0087368 THERMOSTAT - BLUE (ROHS)
$73.40
W0087464 ROLLER REAR GREY
.JPG)
W0088096 MOTOR FAN EVAP
W0088199 HEATER DEF & DTT R600A 790W
W0088223 LID CRISPER ASSY
W0088802 SHELF GLASS EBE NW
W0103409 LAMP 40W SES OVEN T29
W0147468 CONTROL HOUSING RF450 ASSY
W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL
W0018042 BRACKET FAN MOTOR
$7.00
W0018049 CLIP SELF ADHESIVE
$9.00
W0018078 SHROUD FAN MOULDED
$16.30
W0018122 DOOR ASSY FIP FC RH SR520C
$271.00
W0018123 DOOR ASSY FIP FC LH WHT SR520C
$272.00
W0018125 COVER HINGE LH
$12.95
W0018166 GROMMET FAN MOTOR
$16.45
W0018170 GROMMET COMPRESSOR
W0018186 DOOR ASSY FIP FZR RH KTM5200WA
$352.90
W0018253 CAP CORNER WHT
$17.05
W0018383 GASKET LAMP SEALING
$7.70
W0018421 BIN BOTTLE
$55.95
W0018618 GASKET ASSY OTM F/C & FRZ 520L
W0078982 STICKER WATTAGE 40W RS662V
W0081199 TIE CABLE 140MM LONG
W0081263 PIN COMPRESSOR MTG RS652M*6
W0082722 FOAM TAPE RJ393V
W0082742 CAP SCREW WHT
W0083235 CLIP-HEATER-ALUMINIUM BJ414Q
W0083869 PLUG DRAIN WHT
W0084491 SEAL BYPASS PLASTIC N410F
W0084558 DAMPER NOISE
W0084749 CLAMP-CORD BJ385T
W0085299 BOX TERMINAL
W0085300 TERMINAL COVER RP342
W0085486 SHELF FREEZER RJ523V
W0085494 INSULATION EVAP COVER RJ523V
W0085599 SPACER ROLLER STRIKESIDE RJ393
W0085622 TROUGH DRAIN SR300B
W0085638 COVER LAMP
$14.90
W0085702 ROLLER ADJUSTABLE RJ393V
W0085947 PLUG SCREW
$3.90
W0086053 THIMBLE FILLER ASSY CLOSED
W0086056 THIMBLE CAM ASSY CLOSED RJ393V
W0086131 COVER TOGGLE LOCK SR300B
W0086322 TRIM SHELF FREEZER 656MM
W0086339 SCREW M4 X 8 MUSH RJ393V
W0086441 GASKET DEL TOP N280J
W0086447 CAP
$12.90
W0086579 TAPE FOAM SEALING SBM3800MA
W0086607 SCREW 6GA 3/4 PAN PH BJ384V
W0086608 CORD SERVICE INSULATED
W0086648 SHELF FC 699.92MM X X386.89MM
W0086829 EPS UPPER KTM3900M
W0086844 KNOB CONTROL KTM4200WA
W0087129 DOOR DAIRY STM5200WA
W0087168 PAN DRAIN
$24.95
W0087176 BIN BOTTLE
W0087190 OVERLOAD T0366 GVT44
W0087325 CAPAC 4*0UF 400V WIRED CLIP
W0087383 EVAPORATOR ASSY
W0087402 SCREW 8/32 X 3/8 ETM3600WB
W0087403 CLIP MOUNTING COMPRESSOR
W0087405 SCREW 12/14 16MM ETM3600WB
W0087406 SCREW-HINGE/CAM-BTM ETM3600WB
$4.50
W0087407 SCREW 8/32 X 1/2THREAD FORMING
W0087409 SCREW EVAP COVER 8 X 1/2
$4.00
W0087411 SCREW HINGE CENTRE
$4.50
W0087412 SCREW ETM3600WB
W0087416 SCREW 8 X 1/2 T/F ETM3600WB
W0087417 NUT ETM3600WB
W0087422 LOCK WASHER ESE6108WA
W0087477 HINGE CENTRE N280J WHITE
W0087594 BASE PLATE COMP ASSY STM5200WA
W0087652 GASKET DOOR FZR
W0087654 GASKET DOOR FC
W0087671 SHIELD LIGHT KTM3900MB
W0087720 COVER EVAP WTM5200PA
W0087730 HEAT SHIELD EVAP COVER
W0087737 TROUGH DRAIN ASSY KTM5200WA
$24.95
W0087742 LAMP 40W SES 240V T25
W0087769 COM 134A GTT66 ELECTROLUX
W0087822 SHAFT ROLLER
$7.00
W0088119 HOUSING CTRL TOP ASSY KELV
W0088131 DOOR ASSY FIP FZR LH KTM5200WA
W0088179 LAMPHOLDER & HARNESS FZR
W0088213 HUMIDITY CONTROL KBM3800MB
W0088226 EPS UPPER KTM3900M
W0088231 COVER EVAP ASSY EBM5107SC
W0088259 BADGE NAMEPLATE
W0088690 SHELF FREEZER RJ523V
W0134824 TAPE TESSA MOL 4761
W0134832 TAPE-FOAM SEAL18X4 14M/RLL.
