KTB2502WB-R — 925060802 01
KELVINATOR — Fridge
Parts for KTB2502WB-R
W0368433 MOTOR FAN DC 3W
W0368613 BIN DOOR SHALLOW 54W EL
$45.75
W0373260 SHELF GLASS ASSY 54W
$50.25
W0375495 CRISPER ASSY TF 54W ONE PIECE
$75.75
W0376337 FRIDGE FAN BLADE
$24.71
W0365812 GROMMET COMPRESSOR
$10.50
W0365942 GROMMET FAN MOTOR
W0367795 COVER SCREW
$3.00
W0368006 SCREW TRILOB M5X16
$4.13
W0368009 CLAMP COMPRESSOR
$3.38
W0368021 SCREW TRUSS 4.2X13
$4.13
W0368597 BIN DOOR FLEX 1/2
$45.75
W0369914 LENS, COVER, AIR CHANNEL
$4.91
W0369917 COVER, FRONT
$310.39
W0369919 BAFFLE, SIDE PLATE, FREEZER
$3.00
W0369920 COVER, EVAPORATOR, REAR
$158.70
W0369921 WATER DRAIN, VALVE
$10.76
W0369923 DRIP PAN, SUPPORT, DEFROST HEA
$13.76
W0369931 COVER, HINGE, TOP, RIGHT,WHT
$4.13
W0369933 COVER, HINGE, TOP, LEFT,WHT
$3.00
W0370044 BIN, DOOR, BOTTLE,54W
$15.75
W0370077 ICE TRAY
$20.63
W0370078 EVAPORATION TRAY
$11.29
W0370081 TUBE, UNIVERSAL, PAN
W0370401 DRIER REFRIGERATION 280 LTR
$17.89
W0371030 CONFIGURED ELECTRONIC, PCBA MA
$124.46
W0372657 BEARING AUTO CLOSER R
$9.00
W0372762 GROMMET FAN PANA DC FAN
$12.75
W0372822 TUBE PROCESS
$15.75
W0372929 TERMINAL BLOCK TH1116Y
$21.00
W0372955 HARNESS MULTIFLOW TF BASIC
$22.50
W0373501 PCB LIGHTING LED HSLB
$83.25
W0374200 SHROUD FAN
$43.50
W0374799 COVER DEODORIZER WHITE
$3.00
W0374841 CLAMP NTC EVAPORATOR
$3.00
W0374933 SEAL FOAM
$6.56
W0374937 TERMINAL COVER JIAX-C
$7.50
W0374983 COVER EVAPORATOR FRONT TF
$10.50
W0375045 SUPPORT ICE T&S
$12.75
W0375077 GEAR CONTROL TEMP
$15.00
W0375117 CAPACITOR RF 4UF-6.3MM
$18.00
W0375133 ICE TRAY
$21.75
W0375170 SWITCH DOOR
$21.00
W0375171 SLIDE CONTROL TEMP
$21.00
W0375252 HINGE BOTTOM BASE RIGHT
$30.00
W0375253 HINGE TOP RIGHT
$30.00
W0375272 HINGE CENTRE RIGHT
$32.25
W0375719 DOOR SPARE FZ KTB2502WA
$204.75
W0376379 COMPRESSOR
W0376918 RAIL, DOOR, SUPPORT, 54W WHT
$5.25
W0378144 TRAY, WINE SET
$22.50
W0378915 POWER CORD
$37.50
W0379854 TRAY, FRIDGE, 54W
$66.75
W0381378 DOOR ASSEMBLY COMPLETE, FC TF230 WHT KEL
$195.75
W0382924 BASE FOOT
W0382926 FOOT LEVER
$22.43
W0382927 FOOT BASE HINGE
