KBM4502WC-R — 925060809 01
KELVINATOR — Fridge

W0368023 CLAMP NTC EVAPORATOR

$3.38

W0368323 HEATER RAD DEF R600 240V BF70W

$80.25

W0373335 COVER CRISPER ASSY BF70 WH

$57.75

W0374077 DOOR SHELF,SP8008,561.2X82MM

$71.25

W0365812 DAMPER, COMPRESSOR, 28.6MMX17MM

$10.50

W0365942 GROMMET FAN MOTOR

W0368006 BOLT, FOOT, M5X16 PH

$2.63

W0368021 SCREW TRUSS 4.2X13

$4.13

W0368404 SHROUD FAN BF

$67.50

W0368443 EGG HOLDER,WHITE,254.8X116.8MM

$14.25

W0368469 LEVER,FOOT

$7.50

W0368758 DRAWER CRISPER SLIDE COVER

$15.00

W0368866 DRIER 12GM(XH9)DBLE/SGLE TAIL

$22.50

W0368883 DRAWER CRISPER SLIDE COVER

$15.00

W0368898 DRAIN,TRAY,276.5X205.3MM

$19.50

W0369890 COMPRESSOR PLATE, ASSEMBLY, 17

$53.78

W0371464 COVER GRID AIR RETURN BF

$3.00

W0371568 TUBE,DRAIN,14.6MM,L=218MM

$13.50

W0372322 CAP,SCREW COVER,RIGHT,20.8MM

$2.63

W0372381 CLAMP COMPRESSOR

$2.63

W0372389 CAP,SCREW COVER,LEFT,20.8MM

$2.63

W0372405 SPACER,DAMPER,3-WAYS

$2.63

W0372467 SUPPORT EVAPORATOR BF

$3.71

W0372499 BAFFLE,SLIDE,FRONT, BF WHT

$5.25

W0372513 BEARING HINGE FZR

$5.25

W0372590 HINGE,TOP,RIGHT

$7.50

W0372597 BEARING AUTO CLOSER R

$8.25

W0372604 PIN,HINGE,MIDDLE

$7.50

W0372618 EXTENSION SLIDE INSERT FZR LH

$7.50

W0372757 TRAY EVAP DRAIN BM/SD 70W

$11.14

W0372799 ROLLER

$14.25

W0372822 TUBE PROCESS

$15.75

W0372933 LENS 3 LEDS CLUSTER GALAGA

$20.10

W0373054 DRAWER BODY BF70

$27.00

W0373078 HINGE,MIDDLE

$30.00

W0373306 BOTTLE SHELF,SP8008, 562X110MM

$53.25

W0373457 EVAPORATOR FF BF70

$75.75

W0373546 GASKET FC BF70

$94.50

W0373596 MULTIFLOW ASSY BF KLVN

$110.25

W0373647 REAR HOUSING PCB COVER

$129.75

W0373684 VALVE DRAIN ASSY BF

$146.25

W0373756 DOOR PACKED FZR D WHT KEL

$202.50

W0373894 DOOR SPARE FC KBM4502WA-R

$378.00

W0374544 COMPRESSOR EMB66CLC

$472.50

W0374827 COVER TOP HINGE RIGHT WHT

$3.00

W0374881 SUPPORT EVAPORATOR LEFT TF

$5.25

W0374882 SUPPORT EVAPORATOR RIGHT TF

$5.25

W0374890 BAFFLE SLIDER FRONT BF

$4.91

W0374902 EPS EVAPORATOR BF 70

$6.00

W0374974 CRISPER GASKET 70

$9.00

W0374998 BEARING HINGE FC TOP TF SL L

$10.39

W0375025 BRACKET MOUNT FAN SURROUND

$12.00

W0375089 TERMINAL BLOCK EMBRACO

$15.75

W0375117 CAPACITOR,RF 4UF-6.3MM

$18.00

W0375161 TERMINAL COVER EMBRACO

$20.25

W0375170 SWITCH, DOOR

$22.50

W0375210 OVERLOAD PROTECTOR EMBRACO

$24.75

W0375214 STARTING DEVICE QPA-20A

$26.25

W0375273 SHELF WIRE BF70

$31.16

W0375392 DRAWER WIRE BASKET LOW 70

$45.00

W0375398 COVER,EVAPORATOR,ASSEMBLY

$48.75

W0375413 DRAWER, CRISPER, FRONT, BF70 KELV

$49.88

W0375453 BIN,SLIDING TYPE,DOOR,SP8008,

$67.50

W0375509 HEATER TUBE DRAIN PAN (TYPE M)

$80.51

W0378291 HARNESS, SENSOR, DEF
