KWH60HRF — 950004804 01
KELVINATOR — Air-Conditioner
Parts for KWH60HRF
W0368842 SENSOR, TEMPERATURE, AMBIENT
$35.25
W0371335 CAPACITOR CBB61S
$17.25
W0371336 MAIN ELECTRONIC BOARD, ODU
$92.25
W0371943 GASKET,COMPRESSOR
$17.25
W0371962 FAN, BLOWING OUTLET, FRONT
$26.40
W0371972 COMPRESSOR, INVERTER, ROTARY
$412.50
W0371979 BLOWING OUTLET, REAR
$19.80
W0371980 FAN MOTOR, ODU
$290.93
W0371981 CHASSIS, ASSEMBLY
$104.78
W0372315 CRANK
$3.00
W0372326 CLIP PROTECTOR EWJ16HRA
$3.00
W0372388 LEVER SUB-ASSY AIR DOOR
$3.00
W0372407 LINKAGE HORIZONTAL AIR GUIDE
$3.00
W0372408 MEMBRANE DECAL
$4.13
W0372419 CLIP RETAINING CHASSIS
$3.00
W0372480 LOURVE AIR
$4.09
W0372485 BOARD LCD (REMOTE CONTROL)
$4.50
W0372525 POWER CORD, PLUG
$2.63
W0372612 SUPPORT, AIR, DOOR
$6.86
W0372648 SENSOR, TUBE
$7.76
W0372707 TRAY, WATER, EVAPORATOR
$9.83
W0372708 CONTROL BOX, COVER PANEL
$9.83
W0372779 CONTROL BOX, ASSEMBLY, WINDOWN
$12.71
W0372970 FAN HOUSING, AIR
$21.56
W0373058 FAN HOUSING, FOAM
$26.44
W0373072 CAPACITOR
$27.60
W0373088 FRONT CASE
$30.75
W0373143 SENSOR TEMPERATURE
$35.25
W0373144 FILTER, AIR, OTHER
$35.25
W0373191 MOTOR, SHUTTER
$38.96
W0373213 PANEL, INTERNAL
$41.18
W0373230 4-WAYS, COIL
$43.50
W0373250 REMOTE CONTROL
$48.75
W0373251 DRAIN VALVE
$48.75
W0373252 FAN BLADE, CENTRIFUGAL
$49.50
W0373431 FAN BLADE, ODU
$72.00
W0373648 PCB, DISPLAY BOARD
$130.50
W0373769 CONTROL BOX, ASSEMBLY, ODU
$217.50
W0373777 4-WAYS, PIPING, ASSEMBLY
$201.71
W0373827 EVAPORATOR, ASSEMBLY
$314.89
