KSV70HRE — 950001222 00
KELVINATOR — Air-Conditioner
Parts for KSV70HRE
W0014946 FILTER CARBON
W0022340 CAPAC 3.5UF450V 4SMALL PIN RUN
$5.52
W0023278 SENSOR TEMPERATURE
W0011173 COMPRESSOR KSV53HRE
$737.18
W0011174 COMPRESSOR KSV70CRE
$1,120.24
W0012095 EVAPORATOR ASSY
$389.81
W0012105 EVAPORATOR ASSY
$271.50
W0012195 CONDENSER ASSY
$501.30
W0012199 CONDENSER ASSY
$635.44
W0012298 CLAPBOARD ASSY
$37.50
W0012309 CLAPBOARD, SUB ASSY
$37.50
W0012335 FRAME, WALL MOUNTING
$22.50
W0012337 BRACKET WALL MOUNTING
W0012347 TOP COVER KSV53HRC
$52.50
W0012388 LEFT SIDE PLATE KSV53HRC
$20.63
W0012389 RIGHT SIDE PLATE KSV53HRC
$33.00
W0012507 REAR GRILL KSV53HRC
$10.73
W0012593 SUPPORT, MOTOR SUB ASSY
$37.50
W0012599 SUPPORT, MOTOR SUB ASSY
$24.75
W0012609 VALVE SUPPORT SUB-ASSY
$9.08
W0012614 SUPPORT, VALVE ASSY
$11.21
W0012951 BOARD MAIN ASSY OUTDOOR ELECT
$464.85
W0012953 BOARD MAIN ASSY OUTDOOR ELECT
W0013018 CHASSIS, SUB ASSY
$150.00
W0013019 CHASSIS, SUB ASSY
$150.00
W0013156 VALVE ASSY, 4-WAY
$194.96
W0013157 VALVE ASSY, 4-WAY
$194.96
W0013189 CAPILLARY, SUB ASSY
$37.50
W0013191 CAPILLARY
$29.14
W0013514 DRAIN PIPE KSV35CRC
$11.40
W0013516 HOSE DRAIN
$22.50
W0013881 COUPLING CONNECTER DRAINAGE
W0013998 SEAL DRAINAGE
$4.50
W0014091 VALVE CUT-OFF SUCTION 5/8
$51.56
W0014094 VALVE, CUT OFF SUB ASSY 1/4
$17.33
W0014098 VALVE, CUT OFF SUB ASSY 1/4
$37.50
W0014099 VALVE, CUT OFF SUB ASSY 1/2
$39.19
W0014464 FAN AXIAL FLOW KSV53HRC
W0014485 FAN, CROSS FLOW
W0014490 BLADE FAN CROSS FLOW ASSY
W0014562 BUSH AXILE LH
W0014563 LOUVER, LOWER GUIDE
$54.15
W0014582 LOUVER, AIR
$3.00
W0014584 LOUVER, AIR 1
$41.21
W0014585 LOUVER, AIR 2
$3.00
W0014631 BUSH AXILE
W0014632 BUSH AXILE
W0014648 CRANK, UPPER
$3.00
W0014649 CRANK, LOWER
$3.00
W0014665 ROD, CONNECTING - LOUVER SWING
$3.00
W0014666 GUIDE, CRANK
$3.00
W0014667 CRANK
$4.13
W0015163 FILTER, SUB ASSY
W0015167 FILTER, SUB ASSY
W0015175 FILTER (HEPPA)
W0018886 MOTOR FAN INDOOR KSV70CRE
W0018893 MOTOR, FAN FN20V-PG
W0018910 MOTOR FAN OUTDOOR KSV62HRE
W0018912 MOTOR FAN OUTDOOR KSV53HRC 01
W0018967 MOTOR STEP KSV70CRE
W0018978 MOTOR STEP KSV53HRE
W0019424 CASE, FRONT
$60.00
W0019453 PANEL, FRONT ASSY
$44.66
W0019456 CASE ASSY, FRONT
$41.25
W0019457 CASE, FRONT
$75.00
W0019458 CASE ASSY, REAR
$97.50
W0019459 CASE ASSY, REAR
$90.00
W0019462 TRAY, WATER ASSY
$37.13
W0019511 COVER, ELECTRIC BOX
$8.25
W0019533 COVER, ELECTRIC BOX
$7.50
W0019535 BOX, ELECTRIC ONLY
$30.00
W0019538 BOX. ELECTRIC ONLY
$30.00
W0019545 INSULATING PLATE OF ELEC BOX C
$9.75
W0019549 BOX ELECTRIC ONLY (FIRE PROOF)
$30.00
W0019604 COVER, BOX ELECTRIC 1
$7.50
W0019607 COVER, BOX ELECTRIC 2
$30.00
W0019936 BOARD MAIN ASSY INDOOR ELECT
$285.00
W0019939 BOARD MAIN ASSY INDOOR ELECT
W0020514 COVER, VALVE
$7.50
W0020562 FRONT GRILL KSV53HRC
W0020564 WINDOW, RECEIVER
$37.69
W0020663 SUPPORT, EVAPORATOR
$7.50
W0020665 BAR, STAY SUB ASSY
$7.50
W0020678 COVER, SCREW
$3.00
W0020769 PLATE, PRESS (CRANK)
$3.00
W0020770 PIPE CLAMP KSV62HRC
$3.00
W0020779 TONGUE, HELICOID
$5.25
W0020787 CLIP, MOTOR FIX
$4.50
W0020789 PLATE, MOTOR PRESS
$22.50
W0020885 HANDLE KSV53HRC
$22.16
W0020946 PANEL, FRONT 11
$37.50
W0020947 LOUVER, UPPER GUIDE
$54.15
W0020949 LOUVER, GUIDE
$14.89
W0021236 BOARD MAIN INDOOR KSV70HRE
W0021238 BOARD MAIN INDOOR
W0021240 MAIN PCB OUTDOOR KSV53HRE
$418.91
W0021300 REMOTE CONTROL
W0021802 BOARD, DISPLAY
W0021803 BOARD, DISPLAY
W0023280 SENSOR TUBE TEMP
$33.04
W0023284 SENSOR TEMPERATURE
W0023290 SENSOR TEMPERATURE
W0023293 SENSOR INDOOR KSV53HRE
W0023350 CORD, POWER
$26.25
W0023356 CONNECTING CABLE(FOUR CORE)
$53.63
W0023357 CONNECTING CABLE KSV62HRC
$127.50
W0024729 TERMINAL BOARD 3-BIT ASSY
$15.00
W0024732 TERMINAL BOARD 4-BIT
$11.18
W0024862 COIL, MAGNETIC (4-WAY VALVE)
$37.50
W0024873 REACTOR KSV70CRC
$74.25
W0024874 REACTOR KSV53HRC
$57.75
W0024938 SWITCH PRESSURE PROTECT
W0025271 RADIATOR
$30.00
W0026747 NUT, FLARE (ONE TIME) 12.7MM
$15.68
W0026748 NUT, FLARE (ONE TIME) 16MM
$19.80
W0026749 NUT, FLARE (ONE TIME) 6.35MM
$8.25
W0026834 BEARING FAN BLADE
W0026850 PLUG WATER TRAY
W0047829 FRONT PANEL KSV53HRC
$87.08
W0096142 SCREW COVER
$3.00
W0096481 PIPE CLAMP KSV26CRC
$3.00
W0096483 CLAMP WIRING
$3.38
W0096528 HANDLE
W0117886 JUMPING CONNECTOR KSV26HRC
$15.00
W0142538 O GASKET CROSS FAN BEARING
W0142539 BEARING. O-GASKET SUB ASSY
