KSV35CRG — 956002867 00
KELVINATOR — Air-Conditioner
Parts for KSV35CRG
W0014920 MOTOR FAN INDOOR
W0019307 KELVINATOR AIRCON OUTDOOR TERMINAL & POWER PCB
$215.00
W0014917 MOTOR LOUVRE
W0014919 MOTOR FAN OUTDOOR
$245.05
W0015091 COMPRESSOR
$735.00
W0015407 SENSOR TEMP ASSY DISCHARGE
$44.00
W0015409 SENSOR AMBIANT TEMP ASSY
$49.35
W0015411 SENSOR AMBIENT TEMP ASSY
$49.50
W0015413 SENSOR PIPE TEMP ASSY
$43.55
W0015415 SENSOR PIPE TEMP ASSY
$43.55
W0015416 RING, MAGNETIC
$4.00
W0016446 FAN CROSS FLOW
W0016447 BLADE AXIAL FLOW
$91.05
W0016451 FILTER AIR
$49.40
W0016452 FILTER AIR FRESHENING
$30.55
W0016453 FILTER AIR FRESHENING
$41.70
W0016455 HOSE DRAIN
$23.20
W0016456 JOINT DRAIN
$4.50
W0016466 HOLDER, REMOTE CONTROL
$13.30
W0016468 LOUVRE VERTICAL
$29.05
W0016470 HOLDER BEARING
W0016471 FRAME PANEL ASSEMBLY
$103.25
W0016473 CHASSIS ASSEMBLY
$263.80
W0016476 COVER CHASSIS RIGHT
$34.40
W0016481 COVER ELECTRONIC BOX
$9.85
W0016484 COVER FAN MOTOR
$91.75
W0016485 LOUVRE HORIZONTAL ASSEMBLY
$29.05
W0016488 COVER ELEC EQUIPMENT
$11.50
W0016490 COLLECTOR WATER
$57.35
W0016492 CAP SCREW
$4.50
W0016493 COVER CHASSIS LEFT
$34.40
W0016494 GRILLE AIR OUTLET
$45.00
W0016496 COVER ELECTRONIC CONTROL BOX
$6.05
W0016499 CLAMP PIPE BOARD
$6.50
W0016502 PANEL ASSEMBLY
$80.00
W0016509 PLATE INSTALLATION
$305.05
W0016511 CHASSIS ASSEMBLY
$200.00
W0016513 SUPPORT LEFT
$15.00
W0016514 COVER PCB OUTDOOR
$16.25
W0016516 COVER TOP ASSEMBLY
$75.00
W0016517 PLATE VALVE
$34.40
W0016518 PARTITION BOARD ASSEMBLY
$45.85
W0016519 PANEL RIGHT ASSEMBLY
$74.70
W0016520 PANEL FRONT
W0016537 SUPPORT FAN MOTOR
$40.00
W0016766 SEAL RING
$4.50
W0016770 BASE BEARING
W0019126 VALVE ASSEMBLY LIQUID
$47.00
W0019127 VALVE ASSEMBLY 4-WAY
$90.00
W0019138 VALVE GAS (SUCTION)
$39.85
W0019141 VALVE LIQUID (DISCHARGE)
$25.35
W0019146 NUT, FLARE NUT 1/2 - 12.7mm
$6.50
W0019147 NUT, FLARE NUT 1/4 - 6.35mm
$4.50
W0019187 EVAPORATOR ASSEMBLY
$315.00
W0019194 CONDENSER ASSEMBLY
$730.05
W0019308 BOARD PCB DISPLAY BOX ASSY
$195.00
W0019315 ELEC CONTROL BOX PCB ASSY
$565.05
W0019319 ELEC CONTROL BOX PCB ASSY
$380.00
W0019326 REMOTE CONTROLLER
$115.05
W0019330 TERMINAL BLOCK
$17.45
W0019332 WIRE ASSY COMPRESSOR
$24.50
W0274358 HANDLE, BIG 'STEEL TYPE
$10.55
W0274813 PCB WIFI BOX ASSY
$33.00
