KSE88CRA — 950001069 00
KELVINATOR — Air-Conditioner
Parts for KSE88CRA
W0014468 BLADE FAN ASSY CROSS FLOW
.JPG)
W0014469 HOLDER BEARING
$7.30
W0067849 MOTOR LOUVRE
W0103211 HOSE DRAIN
W0014361 COVER TEMP SENSOR
$5.50
W0014372 CLAMP CAPACITOR
$4.00
W0014451 INDICATOR HOLDER ESE24CRB
$6.60
W0014467 LEFT CONNECTOR LOUVRE MSE30CR
$5.50
W0014470 COVER CHASSIS REAR LH
$11.00
W0014471 BACK COVER FOR CHASSIS, RIGHT
$11.00
W0014472 BRACKET FAN MOTOR INDOOR
$18.35
W0014473 FILTER AIR
W0014475 PAN DRAIN
$24.90
W0014478 FUSE
W0019552 DISPLAY BOARD ENCLOSURE
$27.50
W0020556 CAPAC 55UF 440V 4PIN COMPRESS
$74.80
W0021118 REMOTE CONTROL
W0068066 CLAMP TEMP SENSOR ESG21HRIA
W0068317 CLAMP
W0068318 CLAMP NET OUTDOOR
W0068321 CLAMP CAPACITOR
W0068324 WASHER FOR WIRE JOINT ESD09HRA
W0068697 UNDERLAY REAR NET MSE30CR
W0068700 CLAMP WIRING
W0069296 HANDLE SMALL
$10.00
W0069301 PANEL FRONT RIGHT
$49.50
W0069524 E-PARTS BOX ESE24CRB
$80.30
W0069577 EVAPORATOR ASSY
W0069590 BUSH (LARGE) MSE30CR
W0069627 WATERPROOF BOARD ESE24CRB
W0069660 SCREW CAP MSE30CR
W0069661 DOWN CLAP FOR PANEL FRAME
$4.00
W0069662 CAP UPPER FRAME
$4.00
W0069665 LEFT MED CONNECTOR LOUVRE MSE3
W0069666 LOUVRE SMALL MSE30CR
W0069667 LOUVRE BIG
W0069668 LEFT HOLDER LOUVRE MSE30CR
W0069670 MED HOLDER LOUVRE
W0069671 MED LOUVRE MSE30CR
W0069672 BUSH SMALL
$4.00
W0069673 RIGHT HOLDER LOUVRE MSE30CR
W0069674 RIGHTR CONNECTOR MSE30CR
W0069675 RIGHT MED CONNECTOR LOUVRE
W0069676 LEFT HOLDER FOR EVAPORATOR
W0069679 COVER MOTOR
W0069680 MOTOR COVER II MSE30CR
W0069681 FILTER HOLDER
$7.00
W0069682 COVER E-PARTS BOX MSE30CR
W0069683 BLADE FAN
W0069686 BOARD MAIN OUTDOOR
W0070322 HOLDER REMOTE CONTROLLER MSE3
W0070655 NUT FLARE TLM B02 3/8 9.52MM
$7.70
W0072244 COPPER NUT TLM-D04 5/8 15.88MM
W0072315 REAR RIGHT CLAPBOARD MSE30CR
W0072316 INSTALLATION PLATE VALVES MSE
W0072501 WIRE JOINT. 5P ESD09HRA
W0072525 EVAPORATOR TEMP SENSOR
W0090059 LOUVRE HORIZONTAL UP
W0090060 LOUVRE HORIZONTAL DOWN
W0090062 CHASSIS
$132.00
W0090064 E-PARTS BOX MSE30CR
W0090066 CORNER BOARD FOR CHASSIS
W0090070 CABINET FRONT ASSY
$68.20
W0093833 PANEL ASSY KSE70CRA
W0094195 CAPILLARY ASSY
$26.40
W0094196 CAPILLARY
W0094711 HANDLE
W0094732 HOLDER FOR REAR NET KSE88CRA
W0094785 MAIN CONTROL BOARD KSE88CRA
W0094818 COMPRESSOR KSE88CRA
W0094944 CONDENSER ASSY KSE88CRA
W0095045 LOW PRESSURE VALVE KSE88CRA
W0095046 HIGH PRESSURE VALVE KSE88CRA
W0095848 CONTACTOR KSE88CRA
W0095849 TRANSFORMER KSE88CRA
W0095850 TRANSFORMER KSE88CRA
W0095851 WIRE JOINT FOR MULTIPLEXER
W0095852 TERMINAL BLOCK KSE88CRA
W0095853 SOFT START CONTROLER KSE88CRA
W0095895 FAN MOTOR KSE88CRA
W0095896 FAN MOTOR KSE88CRA
W0095898 CAPACITOR. SOFT STARTER
W0095899 FAN MOTOR CAPACITOR KSE88CRA
W0095915 INDOOR TEMP SENSOR KSE88CRA
W0096045 BOARD DISPLAY INDOOR
$184.00
W0129523 CAPAC 5UF 45OV 4PIN KPK35CRA
