KSE26HRB — 950132767 00
KELVINATOR — Air-Conditioner
Parts for KSE26HRB
W0014359 FILTER AIR
W0068065 HOLDER FILTER
W0069459 HOLDER BEARING
W0072500 MOTOR FAN
W0075340 SENSOR TEMP EVAPORATOR TEMP
W0093746 FILTER AIR (RIGHT)
W0093747 FILTER AIR (LEFT)
W0093749 FRAME AIR OUT ASSY
$40.00
W0094309 MOTOR OUTDOOR
$195.20
W0103211 HOSE DRAIN
W0014361 COVER TEMP SENSOR
$5.50
W0019589 CLIP CAPACITOR
$4.50
W0019615 REAR NET KSE26CRB
W0019621 MOTOR MOUNTING BRACKET ASSY
$9.90
W0019622 MOTOR MOUNTING BRACKET ASSY
$9.90
W0019625 PARTITION PLATE KSE26CRB
$7.70
W0019738 VALVE 4-WAY
$49.60
W0019739 4-WAY VALVE KSV26HRB
W0019742 VALVE GAS
$50.00
W0019758 VALVE LIQUID ASSY
$51.70
W0019759 VALVE ASSEMBLY 4-WAY
$200.20
W0019862 CAPAC 1.5UF 450V 2PIN SOLDER
W0019910 BOARD DISPLAY ASSY
$149.70
W0068069 INDOOR TEMP SENSOR
W0068318 CLAMP NET OUTDOOR
W0068319 BLADE FAN
$54.90
W0068320 BIG HANDLE
W0068324 WASHER FOR WIRE JOINT ESD09HRA
W0068682 PLATE INSTALLATION
W0068703 PAN DRAIN
W0068916 MOTOR LOUVRE
W0069462 CLAMP CONNECTING PIPE
W0070654 NUT FLARE TLM A01 1/4 6.35MM
$7.70
W0070655 NUT FLARE TLM B02 3/8 9.52MM
$7.70
W0072501 WIRE JOINT. 5P ESD09HRA
W0072508 COUPLING PIPE DRAINAGE INDOOR
W0093667 BLADE FAN CROSS FLOW ASSY
W0093706 BRACKET EVAPORATOR LH
$6.60
W0093712 SUPPORT LOUVRE
$4.50
W0093713 CHASSIS
$99.00
W0093714 MOTOR COVER KSV35HRA
$11.00
W0093715 ELECTRONIC CONTROL BOX
$77.00
W0093716 COVER CONTROL BOX ASSY
$11.00
W0093745 LOUVRE HORIZONTAL
W0093748 FRONT PANEL ASSY KSE26HRB
W0093750 WINDOW COVER FOR REPAIRING
$8.80
W0093753 SCREW CAP KSV35HRA
$5.50
W0093758 VERTICAL GRILLE KSV26HRB
W0093760 CABINET FRONT ASSY
$41.80
W0093837 SMALL HANDLE KSV26CRB
$11.00
W0093887 PLATE INSTALLATION
$10.00
W0093895 INSTALLATION BOARD, E-PARTS
$14.30
W0093897 FRONT NET KSE26CRB
W0093900 BASE PLATE COMPRESSOR
W0093904 FRONT PANEL OUTSIDE KSE26HRB
$49.50
W0093910 TOP COVER ASSY KSE26CRB
$29.05
W0093914 RIGHT CLAPBOARD KSE26CRB
$38.50
W0093992 BOARD MAIN CONTROL
W0094039 COMPRESSOR
$315.00
W0094069 EVAPORATOR ASSY
$383.50
W0094095 CONDENSER COIL ASSY KSE35HRB
$265.90
W0094097 CONDENSER COIL ASSY KSE26CRB
W0094157 VALVE 4-WAY
$240.00
W0094161 VALVE LIQUID ASSY
$50.00
W0094282 TERMINAL KSE35HRB
$13.20
W0094283 TERMINAL KSE26CRB
W0094304 MOTOR INDOOR KSE26CRB
W0094316 MOTOR OUTDOOR KSE26CRB
$93.50
W0094337 CAPAC 25UF 450V 2&4 PIN COMP.
W0094349 CAPAC 2.5UF 450V 4PIN FAN RUN
W0094448 REMOTE CONTROLLER KSV80HRB
W0102580 SEAL CIRCUIT
$4.00
W0127091 LIQUID PIPE VALVE ESD18HRB
