EWF14742 — 914900362 02
ELECTROLUX — Washing Machine
Parts for EWF14742
W0016638 GASKET DRUM SHAFT
$22.84
W0016971 TRANSIT BOLTS KIT
W0016982 ELECTROLUX SIMPSON FRONT LOADER WASHER DUAL INLET (2 WAY) VALVE
W0017020 PIN DOOR HINGE
$8.00
W0017025 RING LOCKING
W0017029 SPRING, BELLOW, TUB, G33
$12.00
W0017112 SHOCK ABSORBER ASSEMBLY
W0017147 GLASS, PORTHOLE
$126.40
W0017199 BOLT SHOCK ABSORBER
W0017214 PUMP ASSEMBLY RECIRCULATION
W0017224 LOW FREQENCY ANALOG PRESSUR
W0017229 PORTHOLE HANDLE SPRING
W0018809 PANEL CONTROL ASSY
W0018821 DOOR, FILTER
W0018857 KNOB CONTROL TC4 SILVER
W0026627 BEARING DRUM (6206Z)
W0027277 ELECTROLUX WASHING MACHINE PCB ASSEMBLY MOTOR CONTROL
$159.20
W0029241 PROTECTION,DOOR SAFETY INTERLO
$27.20
W0074278 ELECTROLUX SIMPSON FRONT LOADER WASHER DOOR LEVER LOCK
W0075951 BELT DRIVE
W0075967 PULLEY PLASTIC
$22.00
.JPG)
W0076254 AEG ELECTROLUX FRONT LOADER WASHER DOOR INTERLOCK SWITCH
.JPG)
W0171419 CLAMP HOSE (SINGLE)13MM-23MM
W0015013 DOOR STOPPER GRAY
$6.68
W0015051 NUT, PLASTIC EWN14991W
$3.60
W0016559 SCREW PULLEY
$3.60
W0016600 COVER SYPHON ADDITIVES
$14.64
W0016613 FOAM RING,ANTIVIBRATION,SK/S
$6.40
W0016630 COUPLING 2 WAY 3 SCOMP
$3.60
W0016881 SCREW SHELL TUB 6 5X50
$3.60
W0016944 CAP REAR PANEL
$12.80
W0017016 CROSSBAR, COMMAND
$22.40
W0017019 PIN CATCHER
W0017051 DISPENSER, DETERGENT
$88.20
W0017065 SUPPORT,WG SPRING, RH
$44.00
W0017066 SUPPORT,WG SPRING, LH
$30.80
W0017082 TOP COUNTER WEIGHT SCREW
$8.16
W0017104 SUPPORT,HOSE DRAIN,HIGH
W0017108 SUPPORT,HOSE DRAIN,LOW
$7.00
W0017118 FLAP,PARTITION,DET DRAWER
$26.20
W0017119 TUBE, CIRCULATION
$18.32
W0017134 SPIDER ASSEMBLY+BUSHING
$86.40
W0017165 PUMP BODY ASSEMBLY JET
W0017171 SCROLL RECIRCULATION
$17.28
W0017174 SPRING SUSPENSION TUB
$11.52
W0017181 COUNTER WEIGHT FRONT,G60W35L
$64.80
W0017196 TUB SHELL ASSY BACK
$148.80
W0017201 BRACKET, SHOCK ABSORB,LEFT
$5.28
W0017202 BRACKET, SHOCK ABSORB,RIGHT
$5.28
W0017204 TUBE INLET DETERGENT
W0017213 TUB SHELL FRONT
$48.00
W0017216 LIFTER DRUM
W0017228 DOOR LATCH SPRING
W0017236 RECICULATION PUMP PROTECTION
$10.32
W0018719 SEAL DRUM OUTER REAR
$21.84
W0018732 CORD POWER SUPPLY AUSTRALIA
$14.60
W0018738 HOSE & CLAMP ASSY FOR SOLENOID
$65.44
W0018742 HOSE & CLAMP FOR SOLENOID VALV
W0018797 FRONT PORTHOLE FRAME,SILVER
$50.40
W0018802 INTERNAL DRAIN HOSE ASSY
W0018831 PORTHOLE FRAME REAR SS
$36.72
W0018835 DOOR, HANDLE SILVER
W0018839 BRACKET METAL PIVOT
W0018840 PORTHOLE HINGE
W0018842 COVER HINGE UPPER SILVER
$9.60
W0018844 COVER HINGE LOWER SILVER
$9.64
W0018846 PANEL,FRONT,HEC STD,WHITE
$112.00
W0018849 LED DIFFUSOR SUPPORT TC4
$7.04
W0026220 CLAMP HOSE
$3.60
W0026228 BEARING BALL 25X52X15
W0026928 ELECTROLUX FRONT LOADER WASHING MACHINE MAIN PCB 807010414H
W0027013 WIRING HARNESS, MOTOR CONTROL
W0027031 PCB SELECTOR EAX1230X TC4
W0027045 STRIP, DOOR LOCK, EMERGENCY
$4.92
W0027176 HOSE, RECIRC.INTAKE
$32.80
W0027186 MOTOR, CONTROLLED INDUCTION HP
$281.60
W0029295 DRUM ASSEMBLY
W0074340 SCREW BEARING SPIDER
W0074343 SCREW MOTOR 5.5 X 38 EWF1092
W0074368 SPRING DOOR PORTHOLE
W0074529 HOUSING DETERGENT DISPENSER
$33.60
W0075275 CLAMP CABLE
W0075542 BUSH HINGE
W0075652 KNOB SEAL
W0075746 COVER DRAIN PUMP CIRCULATION
$11.84
W0075997 FOOT ADJUSTABLE ASSY
W0076150 DRAIN PUMP Leily 50 HZ
W0076158 PIPE INLET SLIM ASSY
W0076164 SCREW COUNTERWEIGHT FRONT8X59
$3.20
W0076169 HEATING ELEMENT(230V.1950W)
W0076180 BELLOWS DOOR GASKET
W0076187 HOSE DRAIN ASSY
W0076220 COUNTERWEIGHT.UPPER.6.4KG
W0076221 PANEL REAR
W0076226 FILTER ASSY
W0076228 HINGE REINFORCEMENT
W0089245 DRAWER DETERGENT
W0089365 PANEL WORK TOP ASSY G50
W0147307 PCB USER INTERFACE ASSY TC4
