EVEP626SC — 944031735 02
ELECTROLUX — Cooker Electric
Parts for EVEP626SC
.JPG)
W0011297 BLADE FAN
W0011319 COVER GRILL DISH
W0011401 DISH GRILL ENAM F/WIDTH BIOS
W0011995 NUT M6 LH FAN MOTOR
$4.50
W0012261 ELEMENT G/BOOST 3000W - PYRO
W0012262 ELEMENT FAN RING 2200W
W0012263 ELEMENT C/HEAT 1800W NO EARTH
$90.05
.JPG)
W0012326 CLIP MOUNTING ELEMENT
W0013450 LOCK DOOR ASSY CAST PYRO NGP
$110.00
.JPG)
W0013581 CHERRY SWITCH D4KS-Y5AA N/O
.JPG)
W0013597 THERMAL CUTOUT 120 DEG N/C 16A
W0013629 TRIM VENT DOOR ASSY NGP UB
$53.20
W0013970 RELAY 30A SINGLE POLE 240V
W0023195 LAMP OVEN HALOGEN 25W
$30.00
W0023201 HOLDER LAMP REAR HALOGEN BIOS
$48.40
W0029326 HINGE 40MM 4 LAYER NGP
W0030474 CONTROL IOI GEN3 PROG EVEP626S
$305.00
W0032275 LAMP 25W 240V G9 PYRO HALOPIN
_1.JPG)
W0050403 MOTOR FAN OVEN
W0053514 SHELF OVEN
$64.00
W0114462 BOARD OVC2000 DUAL CAV
W0011114 TERMINAL BLOCK W/EARTH BIOS
W0011264 PLATE CVR TERM ELEC BIOS
$13.85
W0011345 BRACKET KRONOS PROBE MOUNT BIO
$12.60
W0011356 BRACKET DOOR SWITCH NGD
$14.50
W0011368 BRACKET HINGE SUPT APOLLO
$22.90
W0011380 BRKT ASSY LWR SWITCH & DR LOCK
$33.65
W0011382 BRKT LWR DOOR LOCK MOTOR
$38.00
W0011467 PNL DUO DR OUT AS PREM PYRO
$150.00
W0011479 PANEL TOP PYRO NGP
$43.20
W0011666 COVER FAN & ELEMENT
$95.75
W0011686 PANEL FAN COVER DUO PYRO RUBY
$59.55
W0011857 SUPPORT ELEMENT
$12.80
W0011883 CHANNEL FRONT DUO RH
W0011926 HANDLE DOOR RUBY
$79.05
W0012129 COUPLING D SHAPE 6MM DIA
W0012325 RETAINER PYRO CATALYSE NGP
$11.30
W0012419 HOUSING DR LOCK CAST PYRO NGP
$30.45
W0012465 ROD LONG DOOR LOCK PYRO
$11.00
W0012639 SENSOR CABLE - 500MM
W0012640 SENSOR CABLE - 900MM
W0012643 HARNESS K2 INTERFACE 783/883
$4.50
W0012726 SEAL OVEN DOOR PYRO BIOS
W0012731 SEAL GRILL DOOR PYRO BIOS
$59.70
W0012758 MOTOR ASSY DOOR LOCK NGP
$63.85
W0012863 GLASS OVEN DOOR INNER PYRO NGP
W0012864 GLASS OVEN DOOR MID PYRO NGP
$67.75
W0012875 GLASS DUO INR PYRO RUBY
$296.65
W0012876 GLASS GR DR MID PYRO DUO
$166.90
W0012993 SPACER HANDLE RUBY PREM 40MM
$10.20
W0012997 SPACER RUBBER GLASS NGP
$8.15
W0013260 SHIELD WIRING
$11.95
W0013323 INSULATION GRILL WRAP PYRO NGP
$61.60
W0013324 INSUL OVEN BACK DUO PYRO NGP
$18.70
W0013343 INSULATION OVEN BACK PYRO BIOS
W0013344 INSULATION OVEN WRAP PYRO NGP
W0013345 INSULATN INSERT BACK PYRO BIOS
$14.30
W0013433 INSERT HANDLE PYRO DUO
$4.50
W0013461 BRACE OVEN REAR B/I BIOS
$24.85
W0013570 LEVER SWITCH DOOR LIGHT MICRO
$42.95
W0013630 TRIM SURROUND C/P 40MM NGP
$39.00
W0013666 DUCT PLATE TOP PYRO NGP
$14.85
W0013667 DUCT PLATE BOTTOM PYRO NGP
W0013730 BUMPER STOP BLK
$6.55
W0014018 SCREW #6 X 9.5MM PAN PHIL ZC
$4.50
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK
$4.50
W0014041 SCREW #8 x1/2 PH2 MUSH WASHER
$4.50
W0014042 SCREW #8 X 1/2 #2PH TC BLK
$4.50
W0014134 SCREW, M4X0.7X53 PAN HEAD
$4.00
W0026349 HOUSING CENTRERING HELP
$14.50
W0027300 COOLING FAN MOTOR ASSEMBLY
W0027398 HARNESS ADPTR DR LOCK UPR OVC2
$19.15
W0027399 HARNESS ADPTR DR LOCK LWR OCV2
$22.35
W0029304 RETAINER PYRO CATALYSE DUO NGP
$7.70
W0029305 CATALYSER 77DIA,12.5H, 64 CSI
$23.10
W0029352 HINGE LEFT SOFTCL 4-L PYRO DUO
W0029353 HINGE 40MM 4 LAYER DUO
$14.95
W0029496 WIRE HARNESS DOOR UPPR OVC2000
$17.60
W0029631 CAP MOUNT F/FRAME 40MM RUBY LH
$4.50
W0029632 CAP MOUNT F/FRAME 40MM RUBY RH
$17.00
W0029801 PLUNGER DOOR SWITCH NGD
$7.05
W0029826 BRACKET SHIELD
$14.30
W0030413 SCREW M4x0.7x53 PAN TX20
$4.50
W0030438 SLIDE DOUBLE EXT LH
W0030439 SLIDE DOUBLE EXT RH
W0030473 F/FRONT ENAM PYRO DUO NGP
$140.00
W0030491 RACK SIDE GRILL DUO ELUX LHS
W0030492 RACK SIDE GRILL DUO ELUX RHS
W0030544 PANEL OV DR OUT ASSY PYRO 40MM
W0038118 COVER RETAINING LATCH
$10.95
W0038121 COVER CLEAN HEAT FULL GALV BIO
W0038807 BRACKET CLEANHEAT MNT DUO BIOS
W0039242 TRAY BAKING PREMIUM ENAM BIOS
W0039639 BASEPLATE
W0042655 CHANNEL FRONT NGP DUO LH
W0042768 PLUG DOME MDP16
W0052286 GLASS & TAPE EVEP
W0063371 CLIP STANDOFF POWERBOARD
W0064446 SCREW #10 X 3/4' PAN PH ZC AB
W0064627 SCREW #4 X16 T25 W/HD PHIL#2
W0103157 SWITCH DOOR LIGHT MICRO
$41.00
W0105875 FILTER CATALYST
W0114491 SWITCH CHERRY
$47.90
W0114700 SENSOR TEMPERATURE PT500
W0154000 HINGE LEFT SOFTCLOSE 4-L PYRO
W0154101 DISH BAKING CAST BIOS
W0154104 RACK SIDE OVEN ELUX LH
W0154105 RACK SIDE OVEN ELUX RH
W0282433 PLUG BUTTON (HEYCO 2633)
