EPAM960.75.GLM — 0132268003
DELONGHI — Coffee Machine
Parts for EPAM960.75.GLM
W0276940 O-RING (D=6.75 T=1.78)
$11.70
W0276958 SCREW (3.5X12)
$11.70
W0276980 MICROSWITCH
$25.40
W0276991 TUBE WITH 2 BUSHES (L97)
$12.60
W0276993 TUBE WITH 2 BUSHES (L270)
$23.30
W0276995 O-RING (D=3.85 T=2)
$12.20
W0276996 SPRING
$11.90
W0276997 FLOWMETER
W0276998 MICROSWITCH
$25.10
W0277008 SPACER
$12.20
W0277010 CLIP (WIRE 1,2 AISI302)
$12.10
W0277012 CONNECTOR
$12.00
W0277014 SCRAPER BRUSH WITH BRISTLES
$12.80
W0277068 POWER SUPPLY CORD WITH PLUG (AU)
$21.00
W0277072 AUTOSTANDBY BOARD
$15.20
W0277082 RUBBER FOOT PAD
$5.00
W0277090 SWITCH (16A 125/250V)
$13.00
W0277091 CONNECTOR
$28.00
W0277100 FILTER (D.40X2.3 TAI-FENG)
$21.50
W0277104 PUMP (ARS 220-240V 70W)
$38.70
W0277113 TUBE WITH 2 BUSHES (L120)
$11.90
W0277114 TUBE WITH 2 BUSHES (L150)
$12.10
W0277116 TUBE WITH 2 BUSHES (L205)
$12.30
W0277124 FIXING BRACKET (NTC)
$11.70
W0277125 STEAM CONNECTION
$12.30
W0277128 RIGHT ANGLE CONNECTION
$11.70
W0277132 GENERATOR GASKET
$11.70
W0277153 ON-OFF KEY
$15.80
W0277165 TUBE (L350)
$13.50
W0277201 STEAM NOZZLE
$14.00
W0277879 DOUBLE CONNECTION
$11.70
W0277882 SOLENOID VALVE (2VA 230V)
$29.00
W0277982 MIXING MAGNETIC PADDLE
$12.10
W0278180 MILK MIXING PADDLE
$26.20
W0305692 MILK SUCTION TUBE
$16.00
W0313141 SOLENOID VALVE (3VA 230V)
$26.10
W0315451 GASKET
$4.50
W0315778 WATER INTAKE TUBE
$13.00
W0325953 DRAWER
$36.10
W0278159 SPARE PART CODE TO BE ADVISED
W0311640 WIRING FOR FLOWMETER (L400)
$15.60
W0311642 TCO WITH WIRING (L390 - L100)
$15.20
W0311643 TCO WITH WIRING (L150 - L80)
$15.00
W0312195 MICROSWITCH (0,1A 250V)
W0312214 WIRED MICROSWITCH (L=150)
$18.20
W0312217 WIRED MICROSWITCH (L=60)
$18.70
W0312223 VENTILATOR(12VDC)
W0313050 TCO (318°C 15A)
$14.20
W0313132 SOLENOID VALVE (3VB 230V)
$26.70
W0313240 MOTOR FILTER BOARD
$17.80
W0313241 SENSOR PCB
$19.60
W0313253 INTERFACE BOARD
$19.90
W0313254 HALL SENSOR (L250)
$23.20
W0313255 PUMP PROTECTOR
$14.80
W0313256 MULTIBEVERAGE BOARD
$41.10
W0313262 DOUBLE NTC PROBE
$24.70
W0313263 DOUBLE NTC PROBE
$23.80
W0313277 REED SENSOR (L680)
$15.80
W0313278 REED SENSOR (L490)
$15.80
W0313279 REED SENSOR (L530)
W0315035 GASKET
$12.90
W0315059 GASKET
$12.90
W0315180 GASKET
W0315229 DOOR PIN (IFD)
$11.70
W0315238 DOUBLE TUBE SHAPE
$11.70
W0315256 RIGHT ANGLE CONNECTOR
$11.70
W0315299 VAPORIZER CONNECTOR CLIP
$12.90
W0315341 RIGHT ANGLE DOUBLE INLET CONNECTION
W0315416 MACHINE CONNECTOR
$11.90
W0315458 TUBE (L110)
W0315461 MICROSWITCH SUPPORT CAP
$11.70
W0315477 MACHINE CONNECTOR
$13.00
W0315618 SILICONE HOSE (DI=3 L=145)
W0315625 RING
$12.90
W0315627 PROTECTIVE RUBBER GASKET
$13.20
W0315628 PEG
$12.90
W0315634 MILK DISPENSER TUBE
$19.50
W0315635 AIR FILTER
$12.90
W0315649 GROUND COFFEE FUNNEL
W0315650 GROUND COFFEE FUNNEL
$12.90
W0315686 FILTER
$12.90
W0315687 MOBILE FUNNEL
W0315688 RUNNER
W0315689 SUPPORT
W0315690 CONNECTION
$12.90
W0315691 COVER
$12.90
W0315692 PCB SUPPORT
$12.90
W0315693 SILICONE HOSE (DI=9 L=90)
$13.30
W0315701 GASKET
W0315707 WATER TANK COVER
$14.30
W0315708 MICRO SUPPORT
W0315709 FINGER STOP GRID
W0315716 CONNECTOR
W0315717 PUSH BUTTON
$12.90
W0315718 REINFORCEMENT
W0315719 STOPPER
$12.90
W0315720 BUSH
$12.90
W0315721 PIN
W0315722 SUPPORT
W0315724 FUNNEL
W0315729 DOOR
W0315730 DRAWER
$15.70
W0315731 CLOSURE
$15.60
W0315732 CLOSURE
W0315733 DRIP TRAY
$23.10
W0315734 FRAME
$19.00
W0315735 CONNECTION
$13.66
W0315736 FILTER
$12.90
W0315737 PIN
W0315738 SUPPORT
W0315739 CONNECTOR
W0315740 COFFEE MEASURING SPOON
$12.90
W0315771 GRID
$14.70
W0315776 SILICONE HOSE (DI=3 DE=6 L160)
$12.90
W0315777 SILICONE HOSE (DI=9 DE=12 L240)
$13.20
W0315782 FLOAT
$12.80
W0315814 TOOTHED BELT
$15.50
W0315839 GASKET
$12.90
W0315847 SHEATH
W0315848 GASKET
W0315849 PUMP SUPPORT
$15.30
W0315850 SOLENOID VALVE SUPPORT
$16.50
W0315851 TROLLEY SLEWING RING
$13.10
W0315852 MICROSWITCH SUPPORT
W0315933 COFFEE BEANS TANK
W0315936 SPONGE
W0317945 O-RING
$12.10
W0319732 TUBE WITH 2 BUSHES (L90)
$13.30
W0319963 FLOW REGULATOR
$17.00
W0319973 LEFT SIDE
$73.80
W0319974 GROUND COFFEE COVER
W0319975 COFFEE BEANS COVER
$34.10
W0319976 RIGHT SIDE
$71.20
W0319977 REAR PANEL
$73.20
W0319978 UPPER COVER
W0319983 SENSOR
$29.70
W0319985 TUBE / 2 BUSHES (PTFE DI2-DE4 L=300)
$13.80
W0319986 EXPANSION CHAMBER
W0319988 ROUND GENERATOR (230V1400W F6.3)
$30.10
W0320000 TUBE / 2 BUSHES (PTFE DI2-DE4 L=125)
$13.20
W0320021 TUBE / 2 BUSHES (PTFE DI2-DE4 L=340)
W0320027 BOARD ASSEMBLY (SW1.0.0 230V)
W0320051 CONTROL SUPPORT
$24.60
W0323285 SPRING
$11.70
W0323300 SPRING
$12.90
W0323301 SPRING
$12.90
W0323302 ROD
$12.90
W0323305 SPRING
W0323458 SPRING
$11.70
W0324213 CUP HOLDER
$112.30
W0325901 MECHANICS VALVE (EPAM)
$42.90
W0325904 CARAFE COUPLING
$23.00
W0325905 DISPENSER
W0325926 GRINDER ASSEMBLY (SX 230V)
$130.50
W0325927 GRINDER ASSEMBLY (DX 230V)
$132.00
W0325941 WATER TANK ASSEMBLY
$67.10
W0325948 COFFEE DISPENSER
W0325949 DOOR ASSEMBLY
W0325950 DUCT
W0325954 SAFETY VALVE
$15.50
W0325955 VAPORIZER (R1070W 230V)
$54.40
W0325957 SAFETY VALVE
$15.60
W0325958 REGULATOR
$65.80
W0325959 HOT WATER SPOUT
$32.20
W0325960 MOTOR ASSEMBLY (230V)
$56.10
W0326013 DRIVE ASSEMBLY (CHIAPHUA 230V)
$142.30
W0326014 TROLLEY
$25.10
W0326015 INFUSER
$27.70
W0326056 CONTROL PANEL ASSEMBLY WITH PCB
W0326079 DRIVE ASSEMBLY (CHIAPHUA 230V)
W0327137 SCREW (3.5X12)
W0327167 DRAIN TUBE
W0327168 DRAIN HOSE
W0327169 TUBE 90°
W0327170 SUPPORT SOLENOID VALVE
