CFE532SB — 940001896 00
CHEF — Cooker Electric
Parts for CFE532SB
W0011401 DISH GRILL ENAM F/WIDTH BIOS
.JPG)
W0012256 ELEMENT GRILL/BOOST 3000W
.JPG)
W0012259 ELEMENT EGO 2000W 180DIA (HI)
.JPG)
W0012260 ELEMENT EGO 1000W 145DIA (HI)
$96.00
.JPG)
W0012326 CLIP MOUNTING ELEMENT
W0013199 SHELF OVEN
W0013577 SWITCH MULTI 4
.JPG)
W0013596 SWITCH THERMAL CUT OUT 190 DEG
W0022807 HINGE DOOR OVEN
W0030434 SEAL OVEN MODULAR PROFILE
W0046262 ELEMENT EGO 1500W 145DIA (HI)
.JPG)
W0057771 THERMOSTAT OVEN
W0273798 ENDCAP HANDLE JONAH
W0011114 TERMINAL BLOCK W/EARTH BIOS
W0011334 BRACKET ASSY ELEMENT 145MM
$12.60
W0011335 BRACKET ASSY ELEMENT 180MM
$18.00
W0011366 BRACKET HOB SUPPORT FRESCO
$9.90
W0011367 BRACKET COUNTER WEIGHT FRESCO
$6.60
W0011690 PANEL SPLASHBACK 540 SS FRESCO
W0011693 PANEL SPLASHBACK 540 WHT FRESC
W0011701 SPALSHBACK 540S/S FRESCO
$28.00
W0011873 CHANNEL SPILL VENT 540 GIO
$22.00
W0012127 BLOCK COUNTERWEIGHT FRESCO
$9.90
W0012166 WASHER LEAF SPRING 1/4
$4.00
W0012315 CLIP THERMOSTAT BIOS
$9.00
W0012417 SUPPORT COUNTER FRESCO
$7.05
W0012629 HARNESS 7 POS SW UR540 200MM
$17.15
W0012630 HARNESS 7 POS SW UR540 270MM
$18.00
W0012641 HARNESS 7 POS SW 710MM FRESCO
$18.00
W0012853 GLASS OV DR IN REFL FRESCO
W0013260 SHIELD WIRING
$11.95
W0013460 BRACE OVEN REAR 540 BIOS
$27.50
W0013663 DUCT OVEN WELDED 540 GIO ELEC
W0013829 KIT HOB SOLID S/S FRESCO
$273.00
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
W0014026 SCREW #8 X 5/16 CSK #2PH AB BK
$4.50
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK
$4.50
W0021318 SCREW M4X5 PHIL HZ
W0021772 PLATE MTG SWITCH MULTI 7 FRESC
$14.30
W0022171 FOOT LEVELING
$16.35
W0022696 COVER LAMP SIGNAL RED
$15.00
W0029350 540 LOWER REAR BRACE
$12.60
W0029662 ANTI TILT PLATE
$15.65
W0030004 SUPPORT ELEMENT GRILL BIOS
$7.00
W0030575 HARNESS EGO 7 POS - LH
$19.60
W0030576 HARNESS EGO 7 POS - RH
$19.60
W0030606 INSULATION OVEN BACK - KNAUF
$15.55
W0037481 PLATE CVR TERM GAS 540 BIOS
W0038745 BRACKET ANTI ROTATE SOLID UC20
W0039903 PANEL CABINET REAR (NO HOLE)
$28.00
W0045532 BOLT STABILISING
W0048099 END CAP CONTROL PANEL FRESCO L
W0048100 END CAP CONTROL PANEL FRESCO R
W0048312 HARNESS 7 POS SW 540MM FRESCO
W0052926 SPACER FOOT UC20
W0053490 RACK GRILL INSERT
W0054085 SHIELD WIRING HOB 540 GIO BIOS
W0054672 INSULATION OVEN WRAP - KNAUF
$63.85
W0065458 NUT HEX M6
$4.50
W0109832 INDICATOR LIGHT NEON FRESCO
W0114312 SWITCH 7 POSITION
W0273922 PANEL KICK 540 GIO S/S FRESCO
$177.80
W0274177 PANEL SIDE GREY PRE PAINT
$54.10
W0275668 KNOB CHEF SILVER ELECT JONAH
$18.00
W0275683 PLATE FOOT MOUNTING
W0275695 HANDLE 54CM JONAH BRUSHED SILV
$16.35
W0275698 CAP TOP LH DOOR JONAH
W0275699 CAP TOP RH DOOR JONAH
W0275705 PANEL ASSY OVEN DR OTR NO TRIM
W0275708 SCREW PF K40X 20 T20 ROUND
W0275746 F/FRONT 540 GIO FRESCO
$50.60
W0282403 PNL CNT JONAH CFE532SB & LENS
$125.05
W0283441 COVER CLEAN HEAT
$9.65
W0284441 ELEMENT BASE 1000W E100
W0364567 ELEMENT BASE 1000W 'U
