KMK761000M — 944066550 07
AEG — Microwave
Parts for KMK761000M
W0017871 ASSEMBLY CONDENSATION MOTOR 24
$260.25
W0022985 HARNESS USER INTERFACE BOARD S
$171.75
W0023180 GRILL SHELF 466X385 . .
W0026274 MOTOR CONVEYOR 230V . .
$130.50
W0026279 HEATING ELEMENT UPPER 230V 190
$110.25
W0026281 MAGNETRON
$173.25
W0026282 TRANSFORMER HV
$335.25
W0026283 MOTOR STIRRER 230V
$83.25
W0026302 SENSOR PT500
$51.00
W0026303 HEATING ELEMENT ROUND 230V 165
$106.50
W0026306 LAMP ASSEMBLY G9 230V 25W
$25.50
W0026518 TOUCH PCB USER INTERFACE BOARD
$256.50
W0026986 GASKET OVEN DOOR
$46.50
W0027116 GRID SIDE R
$51.00
W0027117 GRID SIDE L
$51.00
W0114339 BUSH, FIXING, OVEN D41116
$6.00
W0114583 HEATING ELEMENT, BOTTOM, 1000W
W0147344 LAMP HALOGEN BULB 25W G9 230V
W0274530 HANDLE INOX
$99.00
W0017784 MOUNTING PLATE BACK
$49.50
W0017802 GASKET HEATING ELEMENT UPPER
W0017828 OVER HEAT PROTECTION THEMO 145
$18.75
W0022555 BOLT TORX B63 5X6
$4.13
W0022556 SCREW TORX 4 X 10 T20
$4.13
W0023126 PANEL BASE
$31.35
W0023165 SCREW MOUNT 4.2MM X 9.5MM
$12.75
W0023181 SUPPORT, HINGE, LEFT
$22.13
W0023182 SUPPORT, HINGE, RIGHT
$22.13
W0023209 CLAMP CABLE 15x 16mm
$3.00
W0023211 CLAMP CABLE 22 MM
$3.38
W0023212 SHIELD, BOTTOM, HEATER, STEAM
$33.00
W0024182 SCREW KIT BUSH HANDLE
$13.50
W0026251 SIDE PANEL LEFT-RIGHT .
$57.75
W0026272 WHEEL CONVECTION FAN .
$40.50
W0026284 SENSOR MAGNETRON NTC
$51.00
W0026286 SHIELD CONVECTION FAN
$12.38
W0026290 BEARING STIRRER
$26.29
W0026291 RETAINER MOTOR
$10.73
W0026296 SUPPORT CONNECTION BOX
$10.73
W0026297 WASHER AXLE 21/11MM
$10.88
W0026299 INNER DOOR FRAME
$114.75
W0026385 NUT FAN
$4.50
W0026450 CLIP FIXING ELECTRONIC 4 8MM
$4.50
W0027064 AXLE STIRRER
$9.15
W0027100 MOUNTING SET FIXING
$22.50
W0027124 RING NUT
$8.25
W0027159 GASKET DOOR MICROWAVE OVENS
$42.00
W0027169 TAPE DRIP PROTECTION FRONT GLA
$57.75
W0027232 PIVOT SIDE GRID
$12.75
W0077100 HOLDER SIDE GRID 4MM PIN
$24.75
W0103137 LOCKING SPRING. 9MM
W0106497 BOLT TORX B63 5X9 5 T20
W0134350 NUT, HEATING ELEMENT, UPPER,M4
$4.13
W0274457 CAP NUT MX6
W0274462 PAN DRIP 466X385X40 MM
$43.50
W0274555 ADAPTOR DOOR HANDLE
$4.13
W0274592 COVER UI
$11.21
W0274634 GLASS FRONT BLACK A 594X332 MM
$126.00
W0274661 UI NOT CONFIGURED
W0274671 PANEL TOP COVER
$102.75
W0274678 CONTROL PANEL, INOX 60CM VCIU
$130.50
W0274698 DOOR OVEN TOP CAP
$13.50
W0274706 PANEL BACK OVEN
$41.25
W0274711 FILTER VOLTAGE
$27.00
W0275092 KIT SCRW COVER
$7.50
W0275323 LAMP GLASS MICROWAVE
W0275336 SPACER FLAT
W0275495 CONFIGURED ELECTRONIC U I
$378.00
W0282766 HINGE DO0R LONG 5.8KG
$44.25
W0282767 HINGE DO0R 7.1KG
$46.50
W0282777 PANEL BACK FAN
W0283243 GLASS DOOR 474X327MM
$62.25
W0363887 TERMINAL BLOCK 3P
$12.00
W0363888 CABINET, FUSE
$18.75
W0364023 ASSEMBLY,COOLING FAN,COMPLETE
$87.00
W0364024 DIODE, HV
$14.85
W0364034 DOOR FRAME
$185.25
W0364228 GASKET, 405MM
$3.00
W0364242 FAN, STIRRER
$8.14
W0366504 POWER BOARD MEC1
$173.25
W0366673 HARNESS POWER BOARD COOLING FA
$45.11
W0366935 SAFETY SWITCH LEFT L
$24.75
W0366979 SAFETY SWITCH RIGHT
$18.75
W0367099 PROTECTION SHEILD OVC3000/5000
$4.95
W0367758 HARNESS POWER BOARD USER INTER
$6.86
W0367765 HARNESS POWER BOARD DOOR SWITC
$43.61
W0374070 COVER TOP MICA
$27.75
W0375332 CAPAC 1.05UF 2300V 6PIN MICROW
$41.25
